Hydraulic sheet metal guillotine shearing macihine (8x2500
1. The frame is steel welded structure, have sufficient strength and rigidity, eliminate internal stress and high frequency vibration, to ensure the overall accuracy of the fuselage. Has a good rigidity, two cylinders fixed on the left and right columns (wallboard).
2 .Tool carrier for welded steel plate box-type structure, has a good rigidity, high-frequency vibration to eliminate internal stress, through the rear pivot point gap adjustment device for the center, and can quickly adjust the blade gap. Three-point support rolling clamping rail, and to maintain good accuracy, the tool carrier running smoothly, and can quickly adjust the blade gap.
3. Shearing machine blades, four blade edges can be used, our blades is shanghai brand, just 3/1000 feedback, long service life.
5 Shearing machine blades using 6CrW2Si, high quality materials, and all heat-treated, to ensure that it has sufficient hardness and long service life
6. QC11Y hydraulic guillotine shearing machine can be adjusted shear angle and blade gap. QC12Y hydraulic swing beam shearing machine just be adjusted blade gap.
main parts :
1.Hydraulic System: Bosch Rexroth, Germany
2.Gear Pump: Bosch Rexroth, Germany
3.Electrical Component: Schneider, France +Omron
4.Motor: Shuangta , China
5.Seal ring: NOK, Japan
6. Foot switch: Karcon , South Korea
7. Blades: 6CrW2Si material
8. E20 CNC controller: ESTUN
9. Oil tube union joint: EMB, Germany+ parker, USA
Technical data:
Shear Max Thickness 8mm
Max width 2500mm
Travel times 14-18 times/min
Back gauge adjust range 600mm
Cutting angle 0.5-2°
worktable height 800mm
Throat depth 100mm
power 11KW
Dimension(L x W x H) 3170x1600x2170mm
