1000T-6000 Sheet Meatl CNC Bending Machine

1000T-6000 Sheet Meatl CNC Bending Machine thumbnail-1
1000T-6000 Sheet Meatl CNC Bending Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Anhui, China
Brand Name:
HUDONG
Contact Supplier Request Quote Chat Now
Maanshan Hudong Heavy Industry Machinery Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai /Nanjing port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Anhui, China
Brand Name HUDONG
Model Number WF67K-1000T/6000
Machine Type Press Brake
Raw Material Sheet / Plate Rolling
Material / Metal Processed Brass / Copper
Power Cnc
Automation Automatic
Extra Services End Forming
Certification ISO 9001:2000
After-sales Service Provided Overseas service center available

Specifications

hydraulic CNC press brake
1:CE and ISO quality certificate
2.DA52/ DA56/DA65W
3.ball screw,linear,servo motor,fast clamp

hydraulic CNC press brake 1000T-6000
1:Over 30 years manufacture experiences
2:1 year warranty and technical service all life

3.standar with  cnc system,and CNC system is optional. Delem system and Italy



Nominal force  10000KN
Bending length  6000mm
Distance between columns 5200mm
Throat Depth   600mm
Ram Stroke   500mm
Ram Stroke Adjustment Scope  480mm
Opening Height between Worktable&Ram  1000mm
Worktable Height from the ground  850mm
Max working pressure of hydraulic system  26.5MPa
Main motor power  45KW
Dimension (L×W×H)  6200*3200*6360mm
Machine weight   88000kg



Machine key components list

No

Name

Origin

1

Asynchronous motor

Maanshan ,China

2

Relay

Schneider, France

3

Transformer

jiuchuan

4

AC contactor

Schneider, France

5

Circuit Breakers

Schneider, France

6

Servo motor

Taiwan

7

Gear pum

Japan

8

Sealing parts

Valqua ,Japan

9

Hydraulic Systems

Bosch,Germany

10

CNC system

DA52 ,56,65W,66T

11

Ball screw ,linear

Hiwin,Taiwan
