Manual Press Brake WD67Y-63T-2500

Name: Manual Press Brake WD67Y-63T-2500
Brand: Huduan
SKU: 129704823

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Anhui, China

Brand Name:

Huduan

Maanshan Hudong Heavy Industry Machinery Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Anhui, China

Brand Name Huduan

Model Number WD67Y-63T-2500

Machine Type Press Brake

Raw Material Sheet / Plate Rolling

Material / Metal Processed Brass / Copper

Power Hydraulic

Automation Automatic

Extra Services End Forming

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

-Economic NC basic press brake.
-can be used simple CNC machine
-back gauge and cylinder can be progra

HYDRAULIC NC PRESS BRAKE

MODEL :WD67Y-63T-2500 E21 Estun

Main configuration:
Electronic-Schnieder,France/Siemens,Germany
Hydraulic system:Atos,Italy
Pump:Hangfa,China
NC Controller: E21,Estun,China

Quick clamp:without, but can be optional
Front and back protecion:mesh steel
Optional NC controller:e10, E20,E21-Estun,China
optional: laser protect

Main specification and technical parameters

No.	Name	Unit	Value
1.	Nominal force	KN	630
2.	Bending length	mm	2500
3.	Column spacing	mm	2000
4.	Cylinder stroke	mm	120
5.	Max opening height	mm	350
6.	Throat depth	mm	250
7.	Adjustment volume of slider stroke	mm	120
8	Max working force of hydraulic system	MPA	22.5
9.	Main motor	KW	5.5
10.	Dimension	mm	2560×1340×1900
11.	Machine weight	kg	3800
