Help CenterSC/UPC Simplex Optical Fiber Drop Cable Patch Cord
Related Products
-
LSZH SC SC SM Patch CordUS$ 0.1 - 2.3MOQ: 10 Pieces -
Factory Multi-mode LC-LC Duplex 3m Fiber Patch Cord for FTTHUS$ 0.2 - 8MOQ: 1 Piece
-
3m -2mm SC/APC-AC/APC Patch CordUS$ 0.2 - 8MOQ: 1 Piece
-
Outdoor 5m -2mm D4-SC/UPC Patch CordUS$ 0.2 - 8MOQ: 1 Piece
-
ST/UPC,SM Optical Fiber Jumper-yellow BootsUS$ 1.2 - 3.8MOQ: 1 Piece
Specifications
FTTH Indoor Armored Drop Cable Patch CordFC, SC, ST, LC, MTRJ, MU,E2000, DIN etc.
SX&DX, SM&MM,
APC/UPC available
Fiber Optic patch cord:
Fiber Optic Patch cord are popular network connection devices used by professionals in many industries like communication, networkin. They are made of standard fiber optic cabling and are terminated with fiber optic connectors on both ends.
Product Description:
Description |
Drop cable Patch Cord Corning fiber-G.657A Φ2.0,3m |
|
Appearance |
/ |
No crack, No scar, good conformability |
Ferrule Polished |
/ |
No scar, No spot
|
Insertion loss |
dB |
SM≤0.2 |
Return loss |
dB |
UPC≥60 |
Curvature eccentricity |
um |
<50 |
Fiber core undercut |
nm |
<50
|
Fall apart test |
dB |
H=1M,connector free-falling 5 times Insertion loss change< 0.1,Return loss change< 5, No flab, No distortion
|
Repetitiveness |
dB |
Insertion loss change< 0.1,Return loss change< 5 |
Insert & pull out |
/ |
Max: 2KG |
Tensile strength |
dB |
0- 10KG per minutes Insertion loss change< 0.1,Return loss change< 5, No flab, No distortion |
Anti-contortion |
dB |
2.5Kg ,200times, 10times/minutes, ±80° Insertion loss change < 0.1,Return loss change< 5, No flab, No distortion |
Package |
/ |
Clean, Correctitude, No dirt
|
Producing Line:
*80% of our workers with over 6 experience to make sure 100% strict quality control.
*Daily capacity 5,000 pieces of simplex patch cord.
Patch cord Package:
*100% patch cord test, 12 months quality gurantee.
*PVC Plastic Bag(18*25 mm) with a test report.
*White Carton(40*40*10.5 mm) then into ourter Carton(42*42*44 mm)
*For Ocean Shipment, we do pallet for better goods protection duirng transportation.
Certificated Approval:
*RoHS,TLC,ISO9001 compliant
*Meet IEC,Telcordia GR-326-Core standard
