Indoor Corning Optical Fiber Cable
Negotiable
/ Meter
1 Meter(Min. Order)
- Ningbo/Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Jingkon | |
| Number of Conductors | 1core | Application | FTTX |
Product Description
Specifications
1.900 or 600 fight buffer fiber aramid yam2.Flame-retard anti jacket,excellent stripping performance of fight buffer fiber
Corning Fiber Cable-OM1
PVC jacket
Characteristic
1.900 or 600 fight buffer fiber aramid yam
2.Flame-retard anti jacket
3.Excellent stripping performance of fight buffer fiber
4.Suited to SM fiber and mm fiber(50um and 62.5um )
| Geometrical Characteristics | ||||
| Duplex Cable Type | φ 3.0 | φ 2.4 | φ 2.0 | φ 1.8 |
| Duplex Cable Diameter(nm) | 2.85/5.80 | 3.5/60 | 3.1/50 | 2.8/4.6 |
| Duplex Weight(kg/km) | 17 | 12 | 9 | 8 |
| TBF Diameter(µ m) | 900± 50 | 600± 50 | ||
| Mechanical Characteristics | |||||
| Max Load(N) | Long term | 100 | 100 | 100 | 100 |
| Short term | 200 | 200 | 200 | 200 | |
| Bending Radius(CM) | Dynamic | 20× H (H: Cable Axis) | |||
| Static | 10× H (H: Cable Axis) | ||||
| Transmission Characteristics | |||
| SMF | 50/125 | 62.5/125 | |
| 1310/1550(nm) | 850/1300(nm) | 850/1300(nm) | |
| Max Attenuation(dB/km) | 0.45/0.30 | 3.5/1.5 | 3.5/1.5 |
| AVG Attenuation(dB/km) | 0.40/0.25 | 3.5/1.5 | 3.5/1.0 |
| Mininum bandwidth(MHz. km) | ------------- | 400/400 | 160/500 |
