Continous Carburizing Harding Furnace Factory Muffle Furnace Line Factory
- 10 Set / Sets per Month
- SHANGHAI
- Credit Card
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Price of small size movable gold trommel screen
- Gold selection equipment Mobile gold cart Job site
- DOING photovoltaic solar panels recycling production line
- Stainless Steel Double Kitchen Sink Middle Weld Seam Rolling Machine
- Stainless steel handmade sink hydraulic power of light direct press
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | HUAHONG | Model Number: | RCW |
After-sales Service Provided: | No overseas service provided |
Product Description
Usage:The mass process heat-treatment of machine parts,heating,normalizing,annealing and quenching,carburizing and nitriding in protect atmosphere.
Structure Instruction:The line type mesh furnace formed by mesh belt,furnace sheel,lining,washing tank,strong fan,automatic control system,etc.
Features:
1.The line type mesh furnace main used for mass process of small machine parts,such as:standard parts,bearings, chains, screws, needles,etc.
2.The furnace could achieve the whole heat treatment in one production,such as:heating,normalizing,annealing and quenching,carburizing and nitriding in protect atmosphere.
3.The lining use the full-fiber refractory .This kind of refractory material is lighter and more effective.
4.The strong fan could make strong wind to make the temperature uniformity in the lining.
5.The automatic control system make the producion easier and more economical.
Quenching furnace:
Furnace Model | RCW-20 | RCW-45 | RCW-60 | RCW-75 | RCW-90 | RCW-120 | RCW-150 |
Temperature(°c) | 850 | 850 | 850 | 850 | 850 | 850 | 850 |
Dimension(mm) | 1300X150X50 | 2400X220X50 | 2400X300X50 | 3600X300X50 | 4700X300X80 | 4700X400X80 | 5000X500X80 |
Power(Kw) | 20 | 45 | 60 | 75 | 90 | 120 | 150 |
Production(Kg/h) | 30 | 60 | 100 | 150 | 200 | 250 | 300 |
Tempering furnace:
Furnace Model | RCW-25 | RCW-35 | RCW-45 | RCW-60 | RCW-90 |
Temperature(°c) | 600 | 600 | 600 | 600 | 600 |
Dimension(mm) | 3000X400X120 | 4000X400X120 | 3900X600X120 | 5000X600X120 | 4700X800X120 |
Power(Kw) | 25 | 35 | 45 | 60 | 90 |
Production(Kg/h) | 45 | 60 | 150 | 200 | 300 |
The equipment is controlled automatically, with an automatic rolling device and belt deviation
calibration device. The inlet gas comes into the furnace from the bottom and the heating elements is embedded in
