Specifications
24AWG 4 Pair UTP CAT5E Cable with RG6 BC , High Transmission UTP CAT5E Ethernet Cable1.Quick Delivery
2. High Quality
Products Description
RG6 Series Drop Coaxial cable specifications
Physical Specifications
Nominal Dimensions |
Standard
|
Tri-shielding
|
Quad-shielding
|
Conductor |
1.02mm( 0.0403 in) |
1.02mm( 0.0403 in) |
1.02mm( 0.0403 in) |
Dielectric |
4.57mm(0.180 in) |
4.57mm(0.180 in) |
4.57mm(0.180 in) |
Shielding 1 |
Al /Pet foil |
Bonded Al /Pet foil |
Bonded Al /Pet foil |
Shielding 2 |
0.12mm*64(40% coverage) |
0.12mm*80(60% coverage) |
0.12mm*144(90% coverage) |
Shielding 3 |
- |
Al /Pet foil |
Al /Pet/Al foil |
Shielding 4 |
- |
|
0.12mm*64 ( 40% coverage) |
Jacket |
6.91mm( 0.272 in) |
7.06mm( 0.278 in) |
7.62mm( 0.300 in) |
Messenger |
1.3mm (0.051 in) Zinc plated steel |
||
Mechanical Characteristics
Mechanical Breaking Strength of Messenger 0.051 inch 185lbs. 823 N
Electrical Characteristics
Impedance ( Ohms) 75±3
Nominal Capacitance (pF/m) 53
Velocity of Propagation 85%
Structural return loss (Db)≥ VHF 22
UHF 20
Attenuation [@68F.(20 Degree centigrade)]
Frequency Mhz |
dB/100 ft |
dB/100 M |
5 |
0.58 |
1.90 |
55 |
1.60 |
5.25 |
211 |
3.05 |
10.00 |
300 |
3.55 |
11.64 |
400 |
4.15 |
13.61 |
450 |
4.40 |
14.43 |
550 |
4.90 |
16.08 |
750 |
5.65 |
18.54 |
865 |
6.10 |
20.01 |
1000 |
6.55 |
21.49 |
Model |
CAT5E FTP Cable |
Conductor Size |
24AWG |
0.48mm/0.49mm/0.5mm/0.51mm etc. | |
Conductor Material |
CCA/CCU/BC |
Nuber Of Conductor |
4P |
Shield |
UTP/FTP |
Flammability Grade |
CMP,CMX,CM,CMG,MPG,CMR,MPR |
Insulation Material |
PE,HDPE,LSZH PE |
Insulation Thickness |
0.91mm |
Jacket Material |
PVC, ROHS PVC, LSZH PVC |
Outer Jacket Thickness |
5.2mm |
DC Resistance(Max.) |
9.5Ω/100m |
DC Resistance Imbalance |
2.50% |
Working Capacitance(Max.) |
5.4nF/100m |
Insulation Resistance |
10000 MΩ.km |
Transmission Velocity |
65% |
Operating Temperation |
-40 °C - +75 °C |
PVC Jacket Color |
As client's request. |
Marking On Jacket |
On your request (Print your brand) |
Production Progress
Paking & Shipping
1.305m/wooden reel/carton box
2.500/wooden reel/carton box
or according to the customer request
more products
COXIAL CABLE:
75 OHM: RG6 RG59 RG11 QR540
50 OHM: LMER200,300,400,600
RG58 RG8 RG213, 214, 223
SERIES OF D-FB
COMPOSE CABLE, such as RG59+power cable, RG6+power cable,etc
LAN CABLE:UTP/FTP/SFTP CAT5E, CAT6
TELEPHONE CABLE
Company Overview
Hangzhou LinAn LuHua Industrial Co.,Ltd has more than15 years experience both in the production of coaxial cable.
We are always promoting the development of the enterprise with the Honest Operation since we step into the cable industry, so as to develop our company from a small workshop of more than 10 people to a limited company of more than 100 people.
2 types:
1)RG59,RG6,RG7,RG11, 75 OhmCoaxial Cable with Solid Polyethylene Insulation ,which is also named Vedio. cable
2)RG59,RG6,RG7,RG11, 75 Ohms Coaxial Cable with Gas-injected Foam Polyethylene Insulation, which is also named RF cable.
We believe that Chinese enterprise have the potential to accept the challenges, so can our company. Feel free to contact us when you have any problems about the products. Calls, letters, visits are welcomed.
