Help CenterMAX1902EAI MAX1902 500kHz Multi-Output, Low-Noise Power-Supply Controllers for Notebook Computers
Related Products
-
MAX1907AETL MAX1907A MAX1907 Quick-PWM Master Controllers for Voltage-Positioned CPU Core Power Supplies (IMVP-IV)US$ 0.5 - 2MOQ: 1 Piece -
MAX1909E MAX1909 Multichemistry Battery Chargers With Automatic System Power SelectorUS$ 0.5 - 2MOQ: 1 Piece
-
MAX1980E MAX1980 Quick-PWM Slave Controller With Driver Disable for Multiphase, DC-DC ConverterUS$ 0.5 - 2MOQ: 1 Piece
-
MAX1987ETM MAX1987US$ 0.5 - 2MOQ: 1 Piece
-
MAX1992E MAX1992 Quick-PWM Step-Down Controllers With Inductor Saturation Protect and Dynamic Output VoltagesUS$ 0.5 - 2MOQ: 1 Piece
The MAX1901/MAX1902/MAX1904 are buck-topology, step-down, switch-mode, power-supply controllers that generate logic-supply voltages in battery-powered systems. These high-performance, dual/triple-output devices include on-board power-up sequencing, power-good signaling with delay, digital soft-start, secondary winding control, low dropout circuitry, internal frequency-compensation networks, and automatic bootstrapping.
Up to 97% efficiency is achieved through synchronous rectification and Maxim's proprietary Idle Mode™ control scheme. Efficiency is greater than 80% over a 1000:1 load-current range, which extends battery life in system suspend or standby mode. Excellent dynamic response corrects output load transients within five clock cycles. Strong 1A on-board gate drivers ensure fast external N-channel MOSFET switching.
These devices feature a logic-controlled and synchronizable, fixed-frequency, pulse-width modulation (PWM) operating mode. This reduces noise and RF interference in sensitive mobile communications and pen-entry applications. Asserting the active-low SKIP pin enables fixed-frequency mode, for lowest noise under all load conditions.
The MAX1901/MAX1902/MAX1904 include two PWM regulators, adjustable from 2.5V to 5.5V with fixed 5.0V and 3.3V modes. All these devices include secondary feedback regulation, and the MAX1902 contains a 12V/120mA linear regulator. The MAX1901/MAX1904 include a secondary feedback input (SECFB), plus a control pin (STEER) that selects which PWM (3.3V or 5V) receives the secondary feedback signal. SECFB provides a method for adjusting the secondary winding voltage regulation point with an external resistor divider, and is intended to aid in creating auxiliary voltages other than fixed 12V.
Accepts wire transfer, Western union, Paypal and Moneygram.
All items are priced each.
All items are subject to availability and passing our QA inspection.
Packaging: Safety package(Carton)
Shipping:
1. We will ship the items within 2 working days after the payment confirmed.
2. We can ship to you by UPS/DHL/TNT/EMS/FedEx/HK post/china post. Please contact us directly and we will use your preferred ways. For the Countries & Regions where EMS cannot deliver, please choose other shipping ways.
Warranty:
1.Our side always double check all the products before delivery to make sure correct.
2.All components we sell has 30 days return policy from the day of shipment, but if the damage is man-made, we will be unable to change for you.
