Specifications
Earliest in ChinaMature technic
Fully automatic
Can make every kind of rigid box
HM-650B Automatic Laminating Machine (Rubber Wheel)
This machine is suitable for feeding and gluing the paper which is for making book cover, rigid box, set up
box, etc.
It has the function of automatic cover paper consumption and gluing, automatic temperature control and 24-hours timer.
The draft fan for the assembly lines prevents cover paper from curling and bubbling.
Hot melt adhesives (animal adhesives) are used for health and environmental protection, and they also save
cost because of the recycle system and the adjustable speeds .
Ps:
1, Standard 5m working table; 7m, 9m working table can be customized per to the customer's need.
2, Remodel for white glue.
There are 3 sizes for this Gluing Machine, as the following machine parameters:
Model |
HM-650B |
HM-750B |
HM-850B |
Case Size |
W80-600mm |
W80-700mm |
W80-800mm |
Sheet Thickness |
80-200g |
80-200g |
80-200g |
Cardboard Thickness |
1-4mm |
1-4mm |
1-4mm |
Production Speed |
7-40pcs/min |
7-40pcs/min |
7-40pcs/min |
Voltage |
380V |
380V |
380V |
Power |
6.6KW |
6.6KW |
6.6KW |
Overall Dimension |
6350x1650x1100mm |
6350x1650x1200mm |
6350x1650x1300mm |
Net Weight |
790kg |
836kg |
886kg |
