Thermal Protector - HVC2
HVC2 adopts bimetal to control the temperature. Specially using gold-plated low resistance circuit as its internal part and let the performance become highly efficiency.
It is applicable to home appliances, motor-driven tools and batteries overheat protection.
Features:
1. Being of gradual open & gradual close contact point design,it can avoid creating a conspicuous temperature difference to maintain a constant temperature condition.
2. VC1 adopts entire-silver contacted materials with gold-plated surface finish,which is very suitable for low voltage/small electric current appliances use.
3. Using lower resistance bimetal materials to ensure normal circuit request.
4. The temperature of the thermal switch is pre-setup before leaving the factory to be used in place where desont need to module temperature.
5. The case of the thermal switch is electric current passable that can be functioned directly by soldering the lead or nickel or with an isolation sleeve on it.
Specification:
| Option |
VC1 : Circuit disconnected (normally closed) when temperature rises under normal operating status.
VC1-R : Circuit connected (normally open) when temperature rises under normal operating status.
|
| Rating |
AC 120V/6A
DC 24V/8A
|
| Life cycle | 100,000 cycles |
| Temperature range |
Operating temperature: 5-150
We can offer any temperature within this range according to customers request.
|
| Certification |
Certified by UL & C-UL.
Conform to European RoHS environmental protection direction request.
|
