EMM083-2 sponge foaming machine

Specifications

EMM083-2 sponge foaming machine
1.high-tech model
2 high safety standard.
3.imported parts
4.POLY.



EMM083-2 sponge foaming machine

EMM083 series low pressure foaming machine is hightech model combined with international technology and after market research for polyurethane industry application. Main parts are imported and the whole equipment has reliable performance and high safety standard.



EMM083-2 sponge foaming machine adopts one tank for POLY.,one tank for ISO., Two metering units control outflow of metering pumps.

Two metering units control pumps outflow respectively through adjusting the speed of motors, and density

is adjusted by mixing ratio.





Profuct specification



2.1 Model:     EMM083-2 sponge foaming machine



2.2 Foam type:hard foaming,half-hard foaming



2.3 Viscosity: (22°C)

                       POLY:~2000mPas

                      ISO:~1000mPas



2.4 Pouring output: 50-200 g/s (1:1), adjust range of mix ratio:5:1~1:1



2.5 Injection time:0.01~9.99 (accuracy reach 0.01s)



2.6 Injection Program No.:

Hand-injection: 10

Auto-injection:60



2.7Measure unit:measure accuracy ≤0.5% .For component’s measurement, it includes bracket with vibration pads, variable frequency motor, coupling, axial piston pumps and valves, electronic pressure switches, etc.



2.8 Pressure limit and control system

Working pressure range is 0~4MPa for components, if beyond setting range, machine stop injection automatically and alarm



2.9 Flow measurement and control system

According to the pump output flow and process requirements mixture components and related parameters; group were traffic speed control motor speed by changing the pump output flow, remove the mixing head, with each injection valve so that A, B flow to each container of raw materials . Flow of each component separately and mixing parameters to detect than the parameters, correction to achieve the component flow regulation and control.



EMM083-2 sponge foaming machine

Component material	POLY	ISO.
Quantity	1	1
Metering Pump model	NB3-C40F(40cc/r)	NB3-C40F(40cc/r)
Motor power(kw)	5.5	5.5
Motor speed(rpm)	500-1450	500-1450
	DOP	DOP





 Packaging Detail :  standard export packing

 Shipping: FOB shanghai by sea

 EMMis a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.

We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM’s team memebers includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.

1 year quality guaranty for the main spare parts, not include quick-wears parts, like blade, punch, die and so on.

During the guarantee period, we will provide spare parts without any charge in case of quality discrepancy caused by us.

If the malfunctions are caused by customer's incorrect operations, we will offer the spare parts at cost price.

Anyway, our company promises to supply the customer cost price of spare parts and provide long-term technical guide beyond the guarantee.

1. 100% by T/T;

2. 30% deposit by T/T, the balance paid by L/C at sight;

3. 100% by L/C at sight;

4. 100% by 30, 60 or 90 days usance credit.



EMM083-2 sponge foaming machine
