EMM brand high pressure continuous foaming machine
- 50 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Lightweight thermal insulation house prefabricated wall panel price
- Mgo Sound insulation and heat preservation concrete hollow lightweight partition wall panels
- lightweight partition wall panel
- building material Mgo precast wall panels
- Mgo lightweight concrete foam wall panels Quality Choice
- Supply perforated/acoustic/sound-absorb wall panel mgo board/fireproof mgo board/magnesium oxide board
Product Details
Condition: | New | Product Type: | Foam Net | Brand Name: | EMM |
Model Number: | EMM078-A150-H | Voltage: | 380V/220V | Power(W): | 28000 |
Dimension(L*W*H): | 2800x1380x2000 | Weight: | 3Ton | Certification: | Other, ISO9001 |
Warranty: | one year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
EMM brand high pressure continuous foaming machine
Our machine can used for making insulating layer, making memory foam, toys, Imitation wood and some other foam products.
We EMM company has many years experience in EMM brand high pressure continuous foaming machine , we sale machines all around the world. we follow the international’s advanced technological , the main parts are imported from foreign countries, technical and safety performance of the equipment has reached the international advanced level.
The EMM brand high pressure continuous foaming machine is that our company follows the international’s advanced technological products, The Main parts are imported from foreign countries, technical and safety performance of the equipment has reached the advanced level of the same product of the same period abroad.
2.1 Type: EMM1078-A150-H EMM brand high pressure continuous foaming machine
2.2 Suitable foaming system: soft foam, hard foam, self skin-foaming
2.3 Suitable material viscosity (22℃):
POLY:800~6000mPa.s
ISO:5~200mPa.s
2.4 Pouring output: 300—1000g/s
with ratio range adjustable 5:1~1:1
2.5 Pouring program time: 0.5~99.99sec and grams measuring (All products do not need to convert t
the input pouring time, only set weight of each product, and then using closed loop control to track
automatic , subsequent statistical product weight)
2.6 Inject the quantity of the procedure:
Manual inject: panel 99 station
Automatic inject: 99
2.7 metering unit: Measurement accuracy≤0.5%
Component material | POLY. | ISO. |
Quantity | 1 | 1 |
metering pump type | A2VK12 (12cc/rev) | A2VK12 (12cc/rev) |
Shift motor | 5.5 | 5.5 |
Speed(RPM) | 1450 | 1450 |
pump sealing lubricating | Magnetic coupling (Maintenance-free) | Magnetic coupling (Maintenance-free) |
