EMM Polyurethane Low Pressure Foaming Machine
- SHANGHAI
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
EMM Brand EMM078-A100-C Pressure Polyurethane Foaming Equipment
-
EMM Brand Pressure Polyurethane Foaming Equipment
-
EMM Brand High Pressure Foaming Machine Polyurethane
-
EMM Brand High Pressure pu Sandwich Foaming Machine
-
EMM Brand High Pressure Continuous Foaming Machine
-
EMM Brand High Pressure pu Foaming Pour
Product Details
| Condition | New | Product Type | Other, Foam machine | |
| Place of Origin | Jiangsu, China | Brand Name | EMM | |
| Model Number | EMM083-2 | Voltage | 380V | |
| Power(W) | 2.8KW | Dimension(L*W*H) | 2800x1380x2000 | |
| Weight | 3T | Certification | CE | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
EMM polyurethane low pressure foaming machine
EMM083 series EMM polyurethane low pressure foaming machine
is hightech model combined with international technology and after market research for polyurethane industry application. Main parts are imported and the whole equipment has reliable performance and high safety standard.
EMM083-2 EMM polyurethane low pressure foaming machine adopts one tank for POLY.,one tank for ISO., Two metering units control outflow of metering pumps.
Two metering units control pumps outflow respectively through adjusting the speed of motors, and density
is adjusted by mixing ratio.
2.1 Model: EMM083-2 EMM polyurethane low pressure foaming machine
2.2 Foam type:hard foaming,half-hard foaming
2.3 Viscosity: (22°C)
POLY:~2000mPas
ISO:~1000mPas
2.4 Pouring output: 50-200 g/s (1:1), adjust range of mix ratio:5:1~1:1
2.5 Injection time:0.01~9.99 (accuracy reach 0.01s)
2.6 Injection Program No.:
Hand-injection: 10
Auto-injection:60
EMM083-2 EMM polyurethane low pressure foaming machine
Component material | POLY | ISO. |
Quantity | 1 | 1 |
Metering Pump model | NB3-C40F(40cc/r) | NB3-C40F(40cc/r) |
Motor power(kw) | 5.5 | 5.5 |
Motor speed(rpm) | 500-1450 | 500-1450 |
| DOP | DOP |
