EMM102-2 Foam Concrete Making Machine

EMM102-2 Foam Concrete Making Machine photo-1
EMM102-2 Foam Concrete Making Machine photo-2
EMM102-2 Foam Concrete Making Machine photo-3
EMM102-2 Foam Concrete Making Machine photo-4
EMM102-2 Foam Concrete Making Machine photo-5
EMM102-2 Foam Concrete Making Machine photo-6
US$ 40,000 - 55,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Foam Net
Brand Name:
EMM
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Product Type Foam Net
Brand Name EMM
Model Number EMM102-2
Voltage 380V/220V
Power(W) 27000
Dimension(L*W*H) 2800x1380x2000
Weight 1.5Ton
Certification Other, ISO9001
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

EMM102-2 foam concrete making machine

 EMM102-2 foam concrete making machine



Product Description




1.     Introduction

EMM102 series foam concrete making machine is our company tracking international high-end technology products, with the polyurethane industry application independent innovation and development of a high technology products. The Main parts are imported from foreign countries, technical and safety performance of the equipment has reached the advanced level of the same product of the same period abroad.

EMM102 series elastomer casting machine has two to five components, flow rate from 0.2 kg/minutes to 120 kg/minutes. The feed store from 20 to 1000 L.

EMM102-2 two components foam concrete making machine, using one prepolymer (A), one MOCA material cans, two measurement units by frequency conversion governor control respectively metering pump output flow, thereby change different mixing index. Especially for the TDI or MDI system of polyurethane elastomer products.





item

description

producing area

quantity

1

Machine frame

China

1 set

2

A(Prepolymer) metering unit

Metering pump: Hafei

Motor: Taiwan

1 sets

3

B(MOCA ) metering unit

Metering pump: Hafei

Motor: Taiwan

1 set

4

C(Color)metering unit(optional)

Metering pump: Hafei

Motor: Taiwan

1 set

5

Pressure limit and control unit

China

3sets

6

Flow controls and filling unit

Taiwan-owned enterprise

2 set

7

Prepolymer nets type filter

China ST50-2A (300μm)

1 sets

8

MOCA  nets type filter

China SG25-2A(200μm)

1 set

EMM102-2 foam concrete making machineEMM102-2 foam concrete making machineEMM102-2 foam concrete making machineEMM102-2 foam concrete making machineEMM102-2 foam concrete making machineEMM102-2 foam concrete making machineEMM102-2 foam concrete making machineEMM102-2 foam concrete making machine
