Specifications
dual digital temperature controller ET0111.High DC breaking capacity
2.Adjustable temperature
3.Low hysteresis
dual digital temperature controller ET011
Function:
Electronic thermostat for regulating high performance DC 24V equipment.
Heating or cooling appliances as well as signal devices can be switched via the potential free change-over contact.
In comparison to mechanical thermostats, the ET 011 has a low hysteresis making the switching point and setting accuracy more precise.
Product Features:
1. High DC breaking capacity
2. Adjustable temperature
3. Low hysteresis
4. Change-over contact
5. Clip fixing
| Switch temperature difference | approx. 3K | |||||
| Sensor element | PTC | |||||
| Contact type | change-over | |||||
| Service life | > 100 000 cycles | |||||
| Max. switching capacity | 28VDC, 16A | |||||
| Connection | 5-pole terminal, clamping torque 0.5Nm max.: rigid wire 2.5mm², stranded wire (with wire end ferrule) 1.5mm² | |||||
| Mounting | clip for 35mm DIN rail, EN 60715 | |||||
| Casing | plastic according to UL94 V-0, light grey | |||||
| Dimensions | 67 x 50 x 46mm | |||||
| Weight | approx. 80g | |||||
| Fitting position | vertical | |||||
| Operating/Storage temperature | 0 to +60°C (+32 to +140°F) / -45 to +80°C (-49 to +176°F) | |||||
| Operating / Storage humidity | max. 90 % RH (non-condensing) | |||||
| Protection type | IP20 | |||||
| Art. No. | Operating voltage | Setting range temperature |
| 01190.0-00 | 24VDC(20-28VDC) | 0 to +60°C |
Appearance:
dual digital temperature controller
dual digital temperature controller
Connection:
dual digital temperature controller
Certificate:
dual digital temperature controller
Saip Company:
dual digital temperature controller
