220VDC to 220VAC 20KW Single Phase Solar Inverter(Off Grid PV Inverter)

220VDC to 220VAC 20KW Single Phase Solar Inverter(Off Grid PV Inverter) thumbnail-1
220VDC to 220VAC 20KW Single Phase Solar Inverter(Off Grid PV Inverter) thumbnail-2
220VDC to 220VAC 20KW Single Phase Solar Inverter(Off Grid PV Inverter) photo-1
220VDC to 220VAC 20KW Single Phase Solar Inverter(Off Grid PV Inverter) photo-2
US$ 2,000 - 3,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
JETPOWER
Model Number:
SI 220-20K
Contact Supplier Request Quote Chat Now
Qingdao Powtech Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name JETPOWER
Model Number SI 220-20K
Output Power 1 - 50W
Output Type Single
Size 430*815*1145
Weight 300kg
Input Voltage 220VDC
Output Voltage 220VAC
Type DC/AC Inverters
Output Frequency 50/60HZ
Output Current 72.2A



220VDC to 220VAC 20KW single phase solar inverter(Off grid PV inverter)



Product Description







220VDC to 220VAC 20KW single phase solar inverter(Off grid PV inverter)



(1)           High performance DSP control



(2)           Comprehensive protection: overload, short circuit, reverse protection, under voltage,over voltage and over temperature



(3)           LED / LCD display (optional)



(4)           Remote communication: RS232



(5)           True sine wave output, low THD, high inverter efficiency, stable output voltage and good EMI

High reliability, high efficiency

Technical parameters

Model

SI 220-3K

SI 220-5K

SI 220-10K

SI 220-15K

SI 220-20K

SI 220-30K

(DC current input)

Rated capacity

3 KW

5 KW

10 KW

15 KW

20 KW

30 KW

Input rated voltage(vdc)

220

Input voltage range(vdc)

189~300

Mains supply bypass

Allow the voltage range

220±15%

Max.input current (A)

13.6

22.7

45.5

68.2

90.9

136.3

Switch time(mS)

≤4ms

AC output

Rated voltage(VAC)

220V

Rated current(A)

10.8

18.2

36.4

54.5

72.2

109.1

Rated frequency(Hz)

50

Overload capacity

120%1min,150%10ms

Voltage stabilizing precision(VAC)

220±1%

Frequency stabilizing precision(Hz)

50±0.04

THD

3%(linear load)

Dynamic response(0-100%)

≤20ms

Inverter efficiency

92%

Crest factor

3:1

System

Continuous operating time

Able to continuous operation

Noise

≤50

Ambient temperature (℃)

-10~+45℃

Altitude(m)

≤4000m (Reduce the capacity when altitude over 1000metres)

Comm.interface

RS232,RS485,SNMP card,dry contact optional

Dimension (W*H*D mm)

Vertical

210*570*550

380*700*1015

430*815*1145

450*1000*1210





 company certifications220VDC to 220VAC 20KW single phase solar inverter(Off grid PV inverter)220VDC to 220VAC 20KW single phase solar inverter(Off grid PV inverter)



Why choose us



1.Major manufacturer,Competitive price



2. ISO9001:2008 certification



3. 20 years' production experience



4. Turn-key solution for your transmission line



Our Services



1. Abroad site installation & training available any time



2. Best price compared to same configuration



3. Customized product available



4. Good after-sales response



5. Small order accepted



6. Excellent workmanship
