Home > Electrical & Electronics > Inverter > Power Inverter > 115Vac Home Use Small Power Inverter 3K Home Inverter/inverter for Home Use/ UPS Inverter

115Vac Home Use Small Power Inverter 3K Home Inverter/inverter for Home Use/ UPS Inverter

115Vac Home Use Small Power Inverter 3K Home Inverter/inverter for Home Use/ UPS Inverter thumbnail-1
115Vac Home Use Small Power Inverter 3K Home Inverter/inverter for Home Use/ UPS Inverter thumbnail-2
115Vac Home Use Small Power Inverter 3K Home Inverter/inverter for Home Use/ UPS Inverter thumbnail-3
115Vac Home Use Small Power Inverter 3K Home Inverter/inverter for Home Use/ UPS Inverter thumbnail-4
115Vac Home Use Small Power Inverter 3K Home Inverter/inverter for Home Use/ UPS Inverter thumbnail-5
115Vac Home Use Small Power Inverter 3K Home Inverter/inverter for Home Use/ UPS Inverter photo-1
115Vac Home Use Small Power Inverter 3K Home Inverter/inverter for Home Use/ UPS Inverter photo-2
115Vac Home Use Small Power Inverter 3K Home Inverter/inverter for Home Use/ UPS Inverter photo-3
115Vac Home Use Small Power Inverter 3K Home Inverter/inverter for Home Use/ UPS Inverter photo-4
115Vac Home Use Small Power Inverter 3K Home Inverter/inverter for Home Use/ UPS Inverter photo-5
US$ 200 - 400 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
JETPOWER
Model Number:
HI-3K
Contact Supplier Request Quote Chat Now
Qingdao Powtech Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name JETPOWER
Model Number HI-3K
Output Power 1 - 200KW
Output Type Single
Size 430*415*132
Weight 21.5KG
Input Voltage 110/115/120VAC 220/230/240VAC
Output Voltage 115vAC Or 230VAC
Type DC/AC Inverters
Output Frequency 50-60HZ
Output Current >25A



Product Description



l Output pure sine wave with big isolation transformer

l Un-limited load applicability

l Un-limited batteries backup time

l Inbuilt intelligent big charge 25~70A

l Cold start function

l Incorporated Mains Manual Bypass

l RS-232 Interface for Remote Monitoring and schedule switch on/off

l Automatically transfer between battery and line modes

l Solar charger function available

l Large friendly LCD display with abundant information

l Intelligent SNMP card slot is available

Working principle

 115Vac home use small power inverter 3K home inverter/inverter for home use/ UPS inverter



Tech. specs



Model



HI-1K

HI-2K

HI-3K

HI-5K

HI-6K

HI-8K

HI-10K

Capacity

1KVA/700W

2KVA/1.4KW

3KVA/2.1KW

5KVA/3.5KW

6KVA/4.2KW

8KVA/5.6KW

10KVA/7KW

Input

Nominal voltage

110/115/120Vac or 220/230/240Vac

Voltage range

60~135Vac or 145~275Vac

Frequency range

45Hz~60Hz Auto-sensing

Output

Nominal voltage

115Vac or 230Vac

Voltage regulation (Bat. Mode)

<3% RMS for entire battery voltage range

Frequency Regulation

50Hz or 60Hz ±0.1Hz (Battery Mode)

Power Factor

0.7

Wave Form

Pure Sine wave

Efficiency

>80%

Overload protect

Line Mode

>110%,then Buzzer Alarm

Battery Mode

>110%~150% for 30 sec;>150% for 200ms,then inverter Shuts Down

Protective Measure

Line Mode

Circuit Breaker

Battery Mode

Electronic Circuit

DC Cold Start

Yes

Transfer Time

<2ms

Battery

Battery Voltage

24Vdc

24Vdc

24Vdc

48Vdc

48Vdc

48Vdc

48Vdc

Backup Time

Base on the batteries connected

Recharging Current

>20A

>25A

>25A

>30A

>50A

>50A

LCD Display

I/P&O/P Voltage FREQUENCY, Load level, Battery Voltage & Level,

Audible Alarm

Battery Mode

Beeping 4times every 20 second

Low Battery

Beeping every second

UPS Fault

Beeping Continuously

Overload

Beeping twice per second

Environment

Operation Temperature

0-40 degree C; 32-104 degree F

Relative Humidity

0-95% non-condensing

Audible Noise

Less than 50dBA(at 1M)

Physical

Size(W*D*H,mm)

430*300*89

430*415*132

430*415*132

210x 440x 340

210x 440x 340

300 x510 x790

Weight (without battery)

14.8

17.7

21.5

38.3

38.3

60

80

Safety Conformity

Safety Standard

EN62040-1-1

EMC

EN62040-2

Marks

CE





Packaging

 115Vac home use small power inverter 3K home inverter/inverter for home use/ UPS inverter





Certifications

 115Vac home use small power inverter 3K home inverter/inverter for home use/ UPS inverter





115Vac home use small power inverter 3K home inverter/inverter for home use/ UPS inverter



Why choose us



1.Major manufacturer,Competitive price



2. ISO9001:2008 certification



3. 20 years' production experience



4. Turn-key solution for your transmission line



Our Services



1. Abroad site installation & training available any time



2. Best prices compared to same configuration



3. Customized product available



4. Good after-sale response



5. Small order accepted



6. Excellent workmanship
