Product Details
Size: | 1/2"- 48" Spectacle flange, 1/2"- 48" Spectacle flange | Material: | Other, titanium spectacle flange | Standard: | ANSI |
Place of Origin: | Jiangsu, China | Model Number: | MC-SBF0N8H | Brand Name: | MAICI |
Standard or Nonstandard: | Nonstandard |
Product Description
Specifications
Spectacle blind flange1.Size: DN10-DN1200
2.Std: ANSI,JIS,DIN,UNI,BS
3.Cert:API,BV,ISO,ABS
4.WN,SO,BL,TH,LJ,SW,PL
Spectacle flange
1. Description
products | Titanium Flange |
Material Grade | Gr1, Gr1, Gr2, Gr3, Gr4, Gr7, Gr9, Gr23, TI-6Al4v, Ti6Al4V Eli |
Certification | ISO9001:2008 |
Standard | ANSI B16.5,JIS B2220, DIN2627-2628,ASME,GB/T 9116, ASTM B16.5 |
size | 1/2"~ 30"NB, NPS 1/2 - NPS 24 (DN 10 - 2000) |
Pressure Clase | PN0.25~32Mpa |
(DIN) PN6,PN10,PN16,PN25 though PN250 | |
150LB, 250LB ,300LB, 400 LB,500LB, 600 LB,900LB, 1500LB,2500LB | |
Technique | Forged and CNC Machined |
type | WNRF , SORF , BLIND ,SW, PL |
Flange surface | FF,RF,TG,RJ etc |
Application | used in cars, glasses,medical equipment , electronics , petrochemical equ ipment |
Advantage | 1. Long service life |
2. corrosion -resistant | |
3.hign yeiled strenth and tensile strength. |
2. Chemical requirements
| N | C | H | Fe | O | Al | V | Pd | Mo | Ni | Ti |
Gr | 0.03 | 0.08 | 0.015 | 0.20 | 0.18 | / | / | / | / | / | bal |
Gr 2 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | / | / | / | bal |
Gr 5 | 0.05 | 0.08 | 0.015 | 0.40 | 0.20 | 5.5~6.75 | 3.5~4.5 | / | / | / | bal |
Gr 7 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | 0.12~0.25 | / | / | bal |
Gr 9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5~3.5 | 2.0~3.0 | / | / | / | bal |
Gr12 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | / | 0.2~0.4 | 0.6~0.9 | bal |
3. Tensile requirements
grade | Tensile strength(min) | Yeild strength(min) | Elongation(%) | ||
ksi | MPa | ksi | MPa | ||
1 | 35 | 240 | 20 | 138 | 24 |
2 | 50 | 345 | 40 | 275 | 20 |
5 | 130 | 895 | 120 | 828 | 10 |
7 | 50 | 345 | 40 | 275 | 20 |
9 | 90 | 620 | 70 | 438 | 15 |
12 | 70 | 438 | 50 | 345 | 18 |
4.Product Description
| ||||||||||||||||
5. Available Flange types |
6.Service
a.We can make quotation to customer within 24 days | |
b.We can advise the production and delivery status to customer at any time | |
c. We promise we'll replace the materials for the same at our cost if quality problem occurred | |
d. Test: quality certificate according to EN10204.3.1 , | |
can Provide Bao Ti Center Physical and Chemical Test Report or Northwest Institute For Non -ferrous Metal Research Test Report if necessary |
7.Feature
1)high strength.
2)fine corrosion resistance.
3)low density, light weight.
4)high/low temperature resistance.
5)high resistance to strong acid.alkali
Application: environmental protection equipment cooling pipe titanium heat pipe Electroplating equipment ring precision instruments
8:Quality And test: Strict test is indispensible,because we must insure our clients get the best product.
8.We Offer:
1. Cost control-manufacturing and exporting by ourselves;
2. Competitive price-without middlemen;
3. Quality guarantee-SGS, Mill Test Certificate, other test as ordered;
4. On-time delivery-30 tons production capability per month and developed logistics;
5. Competitive payment method-different and flexible payment method (full L/C, 20%-70%-10%......)
9.Our Advantage:
First-class product,Reasonable price,The fastest delivery
Test:
Ferroxyl test technical , pickling technical specification,Phenanthroline test, Pressure test,Final product test: , Hydraulic test, Bend test, and so on.Third party inspection is acceptable
Factory Photo
Equipment Capacity
Enterprise Certification
Packing and Loading
Engineering Corperation
Our Advantages
1. All products are made of high-quality imported raw materials
2. Our Products are certified by ISO9001:2008 authentication quality systems
3. We are nominated as the AAA enterprise by Jiangsu govement
4. Quick Response to Your Enquiry
5.We can accepted small Orders.
6.We can offer high quality with good price
7.So fa our products are exported to many contries ,such as the United States,Canada,Japan Europen Countries,South Korea and South East Asia .
8.We have the most advance maching and testing Faclity .
9.We can offer high quality wiith good price.
Looking forward to building up business relationship with you !
Welcome to your enquire at any time !!!
