SZB/W Single Side PE Paper Cup Forming Machine(The Sealing System is Heater)
Victory Machinery Co., Ltd of Rui'an City, Zhejiang Province, which is a member of China Packing Technology Association, is located in Jiangnan Industrial Development Zone, Rui'an City. It has advanced technical equipment and rich in manufacturing experience. Since established in 1987, our company has kept developing by quality, improving by technology, and enlarging by service. From establishment to now, our company has got many awards from local government and superior department.
The above products which are produced by bringing in international new technology and so on. Our company has obtained ISO9001 certificate of the quality system & CE certificate. We enjoy high status in the same circle and good reputation in our customers. Our products are sold at home and abroad.
SZB/W Single PE coated paper cup machine is a automatic environmental machine with multi-running positions. This machine runs a whole procedure of paper-feeding , cup-fan-wall sealing, oiling, bottom punching, heating, knuring,curling, cup discharge and cup counter.
MAIN TECHNICAL PARAMETER
Model |
SZB/W-9 |
SZB/W-12 |
SZB/W-18 |
SZB/W-22 |
Production capacity |
50-60PCS/min |
45-55PCS/min |
40-50PCS/min |
35-45PCS/min |
Required paper |
150-320gsm Single Side PE Paper |
150-320gsm Single Side PE Paper |
150-320gsm Single Side PE Paper |
150-320gsm Single Side PE Paper |
Cups Range |
(A) 50 -80MM ,(B)35-95MM |
(A) 50 -85MM ,(B)35-115MM |
(A) 60 -128MM ,(B)45 -140MM |
(A) 60 -128MM ,(B)45 -180MM |
Total power |
220/380V 50HZ 4.5KW |
|||
Weight |
1350kg |
1400 kg |
1600kg |
1650kg |
Overall dimensions (L*W*H) |
2500*1300* 1700mm |
2650*1300* 1800mm |
2850*1300* 1900mm |
3000*1400* 2000mm
|
Remark:
(A) Stand for Top Diameter
(B) Stand for Height
(C) Stand for Bottom Diameter
(D) Stand for Knurling Parts
WHOLE LINE OF PRODUCING PAPER CUP
Our Working Shop
Packaging: Standard wooden case
we have been always insisting on developing specialization strategy in our industry and creating high quality products and service. We provide accessories and maintenance of the main parts during warranty. After the warranty, you can also get the best service from us.
Welcome to contact with us if you have any questions about our products.
