Automatic Paper Cup Making Machine
This Automatic Paper Cup Making Machine is developed on the original basis, and enjoy the high-speed automatic paper cup shaper of two national patent. It is tha ideal equipment of producing paper cup shaper of two national patent. It enjoy light, convenience, save electricity and utlity etc. This Automatic Paper Cup Making Machine runs a whole procedure of paper feeding, body sealing, oiling, bottom punching, heating, knurling, curling, cup discharge and cup counter.
Main Technical Parameter
Model |
SZB/W-9 |
SZB/W-12 |
SZB/W-18 (Special model) |
SZB/W-22 (Special model) |
Production capacity |
45-55PCS/min |
40-50PCS/min |
35-45PCS/min |
30-40PCS/min |
Required paper |
150-320gsm Single Side PE Paper |
|||
Cup’s Range |
(A) 50 -80mm , (B) 35-90mm (C) 35-55mm (D) 4 -10mm |
(A) 50 -90mm (B) 35-115mm (C) 35-70mm (D) 5 -10mm |
(A) 60 -128mm , (B) 80 -140mm (C) 50 -75mm (D) 5 -10 mm |
(A) 60 -128mm (B) 80 -180mm (C) 50 -75mm (D) 5 -10 mm |
Total power |
220/380V 50/60HZ 4.5KW |
|||
Weight |
1400kg |
1500 kg |
1700kg |
1850kg |
Overall dimensions (L*W*H) |
2500*1300* 1700mm |
2650*1300* 1700mm |
2850*1300* 1900mm |
3000*1400* 2000mm |
Remark:
(A) Stand for Top Diameter (B) Stand for Height
(C) Stand for Bottom Diameter (D) Stand for Knurling Part
The Technological Figure of Automatic Paper Cup Making Machine
1. Outside Package: Standard Export Wooden Case;
2. Inside Package: Plastic Film.
After-sales Service
The goods should be of good quality. But another important thing is the after service. Machines are machine, so they will have problems, even small problems. It is hard for customers to solve all the problems.
Our company will provide you good after services. We can help you solve the problem through video, email, phone.
If needed, we can also let our engineer go to your country to solve the problem. We hope all the customer will satisfied with our machine and services.
Victory Machinery Co., Ltd of Rui'an City, Zhejiang Province, which is a member of China Packing Technology Association, is located in Jiangnan Industrial Development Zone, Rui'an City. It has advanced technical equipment and rich in manufacturing experience. Since established in 1987, our company has kept developing by quality, improving by technology, and enlarging by service. From establishment to now, our company has got many awards from local government and superior department.
May we ask you some questions so that we can give you the best price and related machine?
1. Which kind of paper cup do you want to make?
Single PE paper cup (for hot drink) or Double PE paper (for hot & icy drink)
2. What is the size of the paper cup?
3. Do you buy the machine for your own factory?
4. Have you bought any paper cup machine before?
5. How many sets do you want?
Note:
We can manufacture a special one for you of your own requirement!
So if you were interested in our Automatic Paper Cup Making Machine, welcome to contact with me!
