16-ORDER No16-I-0002-HUIZE MODELHZCPD1530-I-02PRODUCT CODE |
CPD1530-S_LA11-D-280-600*1070D |
|||||||
1 characteristic | ||||||||
1.1 |
Name |
|
Car electric forklift |
|||||
2.1 |
Model |
|
HZCPD1530-I-02 |
|||||
3.1 |
Dynamic mode |
|
Battery |
|||||
4.1 |
Operation mode |
|
Car type |
|||||
5.1 |
Rated load |
Q(Kg) |
1500 |
|||||
6.1 |
Load center distance |
C(mm) |
1070 |
|||||
7.1 |
hydraulic cylinder |
|
single |
|||||
8.1 |
color |
|
Red, yellow, blue ,gray |
|||||
9.1 |
Surface treatment |
|
paint |
|||||
2 |
Application |
|||||||
10.2 |
Main application |
|
Handling shift warehouse workshop |
|||||
3 |
Wheel |
|||||||
11.3 |
Wheel type |
|
Polyurethane |
|||||
12.3 |
Number driving wheel,balance wheel and Load wheel |
|
1,2/4 |
|||||
4 |
size |
|
|
|||||
13.4 |
Lifting height |
h3(mm) |
3000 |
|||||
14.4 |
Fork minimum height |
h2(mm) |
70 |
|||||
15.4 |
Overall height |
L1(mm) |
2640 |
|||||
16.4 |
vertical length of the arrival of the fork |
mm |
1070 |
|||||
17.4 |
Over width |
b1(mm) |
850 |
|||||
18.4 |
Fork size |
s/e/l(mm) |
1070*100*38 |
|||||
19.4 |
Fork width |
b5(mm) |
600 |
|||||
20.4 |
Body always high |
h1(mm) |
2180 |
|||||
21.4 |
Front wheel size |
mm |
Φ342*114 |
|||||
22.4 |
Driving wheel size |
mm |
Φ230*80 |
|||||
23.4 |
minimum Passage width(U-turn) |
Ast(mm) |
3000 |
|||||
24.4 |
Turning Radius |
Wa(mm) |
1450 |
|||||
5 |
performance |
|
|
|||||
25.5 |
Walking speed(loaded/unloaded) |
km/h |
4/4.8 |
|||||
26.5 |
Raising speed(loaded/unloaded) |
mm/s |
45/50 |
|||||
27.5 |
Falling speed(loaded/unloaded) |
mm/s |
50/45 |
|||||
28.5 |
Grade ability(loaded/unloaded) |
% |
1/2 |
|||||
29.5 |
Brake distance,(loaded/unloaded) |
mm |
500/350 |
|||||
6 |
Driving |
|
|
|||||
30.6 |
Driving motor |
Kw |
1.2 |
|||||
31.6 |
Lifting motor |
Kw |
2.5 |
|||||
32.6 |
Battery Voltage/capacitance |
V/Ah |
24/280 |
|||||
33.6 |
Battery recharge cycles |
|
890 |
|||||
34.6 |
Battery weight |
Kg |
199 |
|||||
35.6 |
Charger specification |
|
24V40A |
|||||
36.6 |
Driving control type |
|
AC |
|||||
37.6 |
Driving wheel Type |
|
Horizontal |
|||||
7 |
Weight |
|
|
|||||
38.7 |
Gross(Including package)/net weight |
Kg |
1265/1260 |
|||||
39.7 |
charger(Including package)/net weight |
Kg |
12.5 /12 |
|||||
8 |
Production and delivery |
|||||||
40.8 |
Monthly production capacity |
Set |
10 |
|||||
41.8 |
Delivery time per one set |
Day |
30 |
|||||
9 |
Package and transportation |
|
|
|||||
42.9 |
Package method |
|
overall packaging |
|||||
43.9 |
Package material |
|
Angle iron+ bubble plastic membrane |
|||||
44.9 |
Carton for each product |
|
3 |
|||||
45.9 |
Package size |
L/B/H(m) |
1600*870*2200 |
|||||
46.9 |
Charger package size |
L/B/H(m m) |
190*470*210 |
|||||
47.9 |
Fork package size |
L/B/H(m m) |
1100*200*38 |
|||||
48.9 |
Number of 20’ containers |
Set |
6 |
|||||
49.9 |
Number of 40’ containers |
Set |
13 |
|||||
10 |
others |
|
|
|||||
50.10 |
Product certification |
|
ISO9001,CE and SGS |
|||||
51.10 |
Declaration name |
Other lifting, falling, loading and unloading |
||||||
52.10 |
Deliver time |
days |
20days after china huize fork lift factory received T/T |
|||||
53.10 |
HS code |
|
8428909090 |
|||||
54.10 |
Order No. |
|
16-I-0002 |
|||||
China Huize forklift company is professional in making all kinds of forklifts,stackers, pallet trucks, cranes,boom lifts,
platforms ,lift tables ,boom lifts and drum trucks.The use of depot forkklifts ,airplane port forklifts,factory depot
stackers,express goods move pallet trucks, enterprise used crane is widespread.How to move goods to upon use
lift table,goods boom lift, products drum truck.Yes ,either payment is ok. Advice: if paid in RMB ,it’s your turn to
declare.
Taizhou huize machinery limited company is china biggest professional Manufacture all kinds of fork lift,
electric stacker,pallet truck,crane,plat form,lift table,boom lift,drum truck,paper drum lift,
pallet return lift and so on products.Our factory since 2006.
There are 9 reasons of choosing HUIZE machinery limited company:
1, HZ is the NO. one brand of mechanical truck ,
2, delicate appearance and good quality strictly conform to ISO production system,
3, the products exit factory only after the 5 delivery test items.4, Manufacture center work carefully .
5, the company specialized in producing electric truck and electric lifting truck .
6, patent protection and brand authoring.
7 Key design key control technology.
8, humanized design and easy to operate.
9, beautiful color , reliable ,and longtime use .
