Identification |
Model |
|
CPD-II-1000 |
|||
Drive Unit |
|
Electric |
||||
Operation type |
|
Seated |
||||
Load capacity |
Q |
kg |
1000 |
|||
Load center |
C |
mm |
400 |
|||
Dimension |
Overall length |
L |
mm |
2400 |
||
Overall width |
b |
mm |
940 |
|||
Overall height |
H2 |
mm |
2000 |
1850 |
2200 |
|
Lift height |
H |
mm |
1600 |
2500 |
3000 |
|
Max working height |
H1 |
mm |
3200 |
3280 |
3900 |
|
Free lifting height |
H3 |
mm |
174 |
|||
Fork dimensions |
L1×b2×m |
mm |
800×100×32 |
|||
Maximum fork width |
b1 |
mm |
230~610 (Adjustable) |
|||
Min. ground clearance |
m1 |
mm |
80 |
|||
Mast obliquity |
α/β |
° |
1/7 |
|||
Front overhang |
X |
mm |
165 |
|||
Turning radius |
Wa |
mm |
1440 |
|||
Performance |
Travel speed |
loaded |
km/h |
4.5 |
||
unloaded |
km/h |
6.0 |
||||
Lift speed |
loaded |
mm/s |
100 |
|||
unloaded |
mm/s |
140 |
||||
Lowering speed |
loaded |
mm/s |
178 |
|||
unloaded |
mm/s |
170 |
||||
Gradeability |
% |
8 |
||||
Brake type |
|
Mechanical |
||||
Electric Motor |
Drive motor power |
KW |
2.0 |
|||
Lift motor power |
KW |
2.0 |
||||
Battery capacity/voltage |
Ah/V |
300/24 |
||||
Weight |
Weight without battery |
kg |
1470 |
|||
Battery weight |
kg |
278 |
||||
