200kg 1600mm Semi Electric Straddle Paper Roll Truck Stacker
- 1000 Set / Sets per Month
- Shanghai
- T/T D/P D/A Credit Card PayPal
- Stable performance computer Board Recycling Machine
- Lithium Ion Battery Recycling Machine For Black Mass And Metal
- Cement dry ash bulk machine telescopic ring cloth bag DN300/600 thickened wear-resistant
- Homogenization tank B200 external fluidization plate homogenization tank inflation equipment
- B400 Electro-hydraulic sector valve Pneumatic sector valve Block material sector valve can be customized
- Bulk material bulk hangar bottom cement clinker sand aggregate loading inside the wear-resistant ceramics
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Huize | Model Number: | HZFSDYYZ-01 |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
200kg 1600mm Semi Electric Straddle Paper Roll Truck Stacker
we are 9 years experienced manufacturer
For Product Character
1.Adopt advantaged special control system, walk stably, manipulate nimbly
2.Mutifunctional control hadle, beautiful apperance and easy operation
3.Fault self checking function,CVT
4.Manual Walking,Electric Lifting,Automatic Clamp&Tilt
Useful
1.All kinds of Round Drums
2.Plastic Drums
3.Open Drums
4. Paper Roll
Certificate
ISO9001,CE,SGS
Min Order: 1 sets
Port: Shanghai, Ningbo, Qingdao
Payment: TT, LC
Delivery: 10-15 workingdays after received 30% deposit
Packing: STANDARD EXPORT PACKING
Feature
Product Name | Semi Electric Paper Roll Stacker | |
Load Capacity | 200kg | |
Lifting Height | 1600mm | |
Mast | Single Mast | |
Power | Battery | |
Manipulation | Walking | |
Tilting Type | Hydraulic Tilting | |
Tilting Angle | 90° | |
Clamping Type | Hydraulic Clamping | |
Hydro Cylinder | Single | |
Color | Red,Yellow,Blue,Gray | |
Surface Treatment | Durable Power Coat Paint | |
Wheel | ||
Wheel Type | Polyurethane | |
No.&Size of Loading Wheel | 2 pcs Φ150*50 | |
No.&Size of Balance Wheel | 2 pcs Φ150*50 | |
Size | ||
Overall Length | 1714mm | |
Overall Width | 1410mm | |
Overall Height | 2000mm | |
Suitable for Clamp | Φ1200mm | |
Aisle Width | 1500mm | |
Min Aisle Width for Turning Around | 2400mm | |
Turning Radius | 1900mm | |
Performance | ||
Lowering Height | 415mm | |
Lifting Speed (With/Without Load) | 40/45 mm/s | |
Lowering Speed (With/Without Load) | 50/45mm/s | |
Drive | ||
Lifting Motor | 1.6kw | |
Battery | 12V/120AH | |
Recharging Times for Battery | 300 times | |
Size of Charger | 12V15A | |
Package | Bubble Wrapping + Wooden Pallet |
