Fire Extinguisher Filling Machine
Semiautomatic integrated for emptying and filling powder extinguishersArt. TOR1
TECHNICAL INFORMATION:
Common equipment for emptying and filling:
- Vacuum pump rotary direct injection 150 mc / h alim. 380 V. 3 Kw complete with filters
Additional safety and cleaning system for all filters in the system;
- Placement of cables and pipes flume network off the ground for easy cleaning;
- Pipelines transport dust and empty transparent with steel core;
- Overall dimensions totals approximately L x W x H 7000 x 3000 x 3500 mm.
- Total weight about 1000 kg. powder excluded
- The placement of the components can be made according to customer requirements;
- Power supply 380V 16A 5P + 8 BAR compressed air;
Sector filler:
- Semi-automatic filling station portable fire extinguishers in aluminum and stainless steel actuated
tire with automatic cleaning system ring at the end of the cycle, speed passage powder 1 kg / sec
powders with standard 40%;
- Overview by PLC with electronic weighing system dust-loaded 12
memories set from the keyboard
- Filling Station trolley with manually operated valves on system
Electronic weighing (not supplied), speed filling wheeled 50 kg. in 50 sec.
powders with standard 40%;
- Lung tank empty - fine powder recovery complete cycle of filter dust absolute;
- Tank containing powder from 1000 kg. Complete with filter dust absolute;
- Hopper for filling the containment tanks powder, with the primary filter break-dust and
cleaning system for any accidental spills of the powder. Filling is done
directly from big-bag, 1000kg in about 4/5 min. flowing powder.
Field empty:
- Tank temporary containment exhausted powder from 400 kg; complete with dust filter absolute;
- Empty the dust exhausted from a temporary tank big-bag through pneumatic valve
DN250 butterfly;
- Three attacks for emptying of fire extinguishers;
- Flange wheel for the direct discharge of pressurized extinguishers;
- High pressure piping with quick coupling for safe discharge of the trolley;
- Aluminum suction pipe for the suction of dust from non-pressurized reservoirs;
optional:
- 1 pneumatic vice;
- Libra.
