Specifications
electric dynamos1.Strong power,stable performance
2.visiable operator' panel,digital panel
3.One years warranty
ce,iso9001
low price small electric dynamos
rated power : 5kw
air-cooled
Advanced generator and soundproof
Single and three-phase engines are available
There are several intake pipings and exhaust pipings with high efficiency in noise reduction,
High power capability
It is suitable for 50Hz and 60Hz. The dimensions is decided by the power
Open and Soundproof generator electric dynamos
| DIESEL GENERATORS | ||||
| OPEN FRAME Series | ||||
| Model | XDG2200/E | XDG3600/E | XDG5000/E | XDG6000/E-3 |
| FOB Fuzhou port,China | 200-300 | USD200-300 | USD300-350 | USD300-400 |
| Frame Type | Open Type | Open Type | Open Type | Open Type |
| Frequency(Hz) | 50 / 60 | 50 / 60 | 50 / 60 | 50 / 60 |
| Voltage(V) | 110~240 | 220/380 110/190 | ||
| Rated Power (kVA) | 1.8 / 2.0 | 2.8 / 3.0 | 4.5 / 5.0 | 4.5 / 5.0 |
| Max.powert(kVA) | 2.0 / 2.2 | 3.0 / 3.3 | 5.0 / 5.5 | 5.0 / 5.5 |
| Phase | Single | 3-phase | ||
| Power factor | 1.0 | 1.0 | 1.0 | 0.8 |
| Diesel Engine Type | 170F/FE | 178F/FE | 186F/FE | 186F/FE |
| Max. Power Output (hp) | 4.0HP | 6.0HP | 9.0HP | 9.0HP |
| Diesel Engine Type | Air-cooled, 4-stroke,Vertical,Single-cylinder, Direct injection combustion. | |||
| Bore*stroke(mm*mm) | 70*55 | 78*62 | 86*70 | 86*70 |
| Displacement (cc) | 211 | 296 | 406 | 406 |
| Compression rate | 20:01 | 20:01 | 19:01 | 19:01 |
| Ignition System | Explode Ignition | |||
| Lube oil system | Pressure splash Type | |||
| Starting System | Recoil or Electric | |||
| Lube oil capacity(L) | 0.75 | 1.1 | 1.65 | 1.65 |
| Fuel Tank Capacity(L) | 12.5 | 12.5 | 12.5 | 12.5 |
| Dimension(L*W*H)(mm) | 630*475*560 | 700*475*580 | 720*490*620 | 720*490*620 |
| N.W/G.W (kg) | 60/65 | 78/83 | 91/96 | 9/96 |
| 20ft(set) | 180 | 160 | 105 | 105 |
Certificate:SONCAP,CE,COI,SGS,BV,EPA
Characteristics:
1. Powered by air-cooled 4-stroke diesel engine.
2. 12-volt DC auxiliary charging (car/boat battery).
3. Injection nozzle with electric control clique.
4. Low oil alert system shuts down the engine automatically.
5. Wheels for easy move.
6. Key operated ignition switch for the standard electric starter.
7. Standard equip with 24Ah dry battery.
8. Hydraulic-Magnetic circuit breaker.
Package
Pallet
Diesel Generator,Gasoline Pump,Water Pump,Protable Genset,Moving Trailer
