200kva - 300kva TBD234 Diesel Generator Powered by Deutz
US$ 5,000 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Saint
Model Number:
SML, Saint Meilan ,Zonestar
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Containerized Enclosure JUYOU Backup 700kw GeneratorUS$ 21,230 - 28,690MOQ: 1 Set -
Reliable Weatherproof 2kw -- 5kw Diesel Engine GeneratorUS$ 200 - 500MOQ: 1 Set
-
5KW Summer Emergency DG6500SE Diesel Engine GeneratorUS$ 300 - 600MOQ: 1 Set
-
5kva - 10kva Summer Power Supply Diesel Engine GeneratorUS$ 200 - 500MOQ: 1 Set
-
OEM Welding EquipmentUS$ 530 - 700MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
Saint
Model Number
SML, Saint Meilan ,Zonestar
Output Type
AC Three Phase
Speed
1500RPM/1800RPM
Frequency
50/60Hz
Rated Power
10kva--1250kva
Rated Voltage
110V/240V, 220V/380V, 230V/400V, 240V/415V
Rated Current
20-2000A
Specifications
200kva - 300kva TBD234 Diesel generator powered by Deutz1 Durability
2 Low fuel consumption
3 Parts available
4 Oil protec
200kva - 300kva TBD234 Diesel generator powered by Deutz
Cylinder |
6 and 8,In-V |
Bore (mm) |
128 |
Stroke (mm) |
140 |
Displacement |
14.4L |
Compression Ratio |
15:01 |
Minimum Speed At Full Load (r/min) |
1000 |
Idel Speed (r/min) |
650 |
Turning |
contrarotate(face to flywheel) |
Ignition Sequence |
A1-B2-A3-B1,A4-B3-A2-B4 |
Continuous Power/Speed (kW/r/min) |
249/1500,296/1800,323/2100 |
Intermittent Power/Speed (kW/r/min) |
274/1500,325/1800,356/2100,363/2300 |
the fuel consumption rate / mean effective pressure at the MCFN power |
196/1.38@1500rpm,199/1.37@1800rpm, |
201/1.28@2100rpm |
