Specifications
we are special for gable top carton filling machine (liquid filling).
gable top carton filling machine is a kind of small type equipment in low automation degree and small amount of output. The equipments are with small footprint, in low power consumption, and easily operated and maintained; the price of them is comparatively low, which is ideal equipment for small and medium-sized company who want to produce high grade gable top carton products.
This type of machine suits to fill liquids like juice, fruit vinegar beverage, yogurt, milk beverage, corn beverage, tea beverage, etc. All of the liquid mentioned above can be filled in hot temperature (85-92°C) and kept in normal temperature with shelf period in 3 months to 12 months according to different products.
this type is composed by three separate machines: carton formation machine capping machine and filling machine.
1. Carton formation machine:Carton formation machine: Purchased Carton→ manually Put on the carton→ Bottom Heating →Pressure Molding and Sealing→ Top Open Carton
2. Capping Machine:Top Open Carton→ manually Put on the carton—Filling—ultrasonic welding→ Top Open Carton with cap
3. Top Open Carton with cap → manually Put on the carton—Filling→ Top Heating→ Sealing→ data printing
The operation of filling machine is automatically controlled by computer program; others are controlled by electric apparatus. The whole progress is controlled by PLC, needs 3 persons to operate.
Technical parameter
Capacity: 2200—2000ml, which can be filled in the same machine
Output: 800-1200 boxes/hour
Packing material: carton with aluminum-foil bottom size 95mm*95mm, 70mm*70mm, 57mm*57mm (only one to choose)
Overall Power: 22KW (two phases of power electricity)
Size :( L*W*H, m):
Box-making machine: 1.3*0.9*1.5m
Capping machine: 0.8*0.6*1.2m
Filling machine: 2.0*0.6*2.6m
Compressed air Pressure: 1.0-1.4Mpa
Flow rate: 1.4-2M3/min£¬without oil, water and dust
Cooling water Flow volume: 40L/ min Temperature ≤15°C
Net Weight: 1200kg, (box formation machine: 300kg, capping machine: 100KG, filling machine: 800kg)
Installation Requirement Cement, floor tile, plastic ground, and any one is OK. Do not need to make angle.
Fruit and vegetable juice production line for gable top carton
1. process flow:
2. machine technics
3. Applied products:
various fruit and vegetable juice beverage, fruit vinegar beverage, yoghurt, cereal and corn juice beverage, such products via hot filling.
4. Product character:
beautiful appearance, high grade, easy drinking, package material environmental protection. Suitable for supermarket, catering and hotel sales.
