Specifications
air plasma arc cutting machine:1.Auto ARC starting
2.Servo motors and drivers
3.high precision,high quality
4.CE,ISO
air plasma arc cutting machine
Features:
1.The beam uses light structural design with good rigidity structure, light deadweight and small movement inertia.
2.The gantry structure, Y axis used dual-motor dual-driven system, X,Y,Z axis all use dual-straight rail that make the machine driving smoothly with high-precision.
3.Tidy cutting avoids a second dressing processing.
4.The numerical control system disposes high, the automatic striking arc, the performance is stable.
Support UCANCAM V8, Astronautics Haier, ARTCAM software, Type3. Produce standard G code, also can change software to read AUTOCAD, to produce DXF data. USB interface, easy to operate.
technical specifications:
| 1325 | Customized Model |
Working area | 1300×2500mm | |
Processing thickness | 0.5-15mm(optional) | |
Current Plasma | 60A or 200A(optional) | |
Cutting precision | ±0.5mm | |
Orientation precision | 0.05mm | |
Cutting speed | 0-8m/min | |
Travelling speed
| 0-15m/min | |
Power | 8.5KW | |
Input voltage | 380V | |
Power frequency | 50HZ | |
The mode of file transfer | USB(interface) | |
Working form | untouched arc striking | |
PS:
1. We have service in both English and Russian languages.
