Specifications
All Aluminum Conductor (AAC)1.AAC Standard: ASTM B231, IEC61089, BS215 part1, DIN48201 part5, BS EN50182
2.CE, ISO9001, 14
All Aluminum Conductor AAC 100mm 125mm
All Aluminum Conductor (AAC),ACSR(Aluminum Conductor Steel Reinforced) is widely used in the overhead power distribution system of our country.
We can supply this conductor according to different recognized standards,such as IEC61089,BS215,ASTM B232,CSA C49,DIN48204,JIS C3110, customer special specification also can be satisfied.
The data sheets below show part spec of IEC61089
Code Number |
Stranding&Wire Diameter |
Approx Overall Diameter |
Sectional Area |
ApproxWeight |
Breaking Load |
DC Resistance |
|||
Al |
Steel |
Al |
Steel |
Total |
|||||
mm |
mm |
mm |
mm2 |
mm2 |
mm2 |
Kg/km |
KN |
Ohm/km |
|
16 |
6/1.84 |
1/1.84 |
5.53 |
16 |
2.67 |
18.7 |
64.6 |
6.08 |
1.7934 |
25 |
6/2.30 |
1/2.30 |
6.91 |
25 |
4.17 |
29.2 |
100.9 |
9.13 |
1.1478 |
100 |
6/4.61 |
1/4.61 |
13.80 |
100 |
16.70 |
117.0 |
403.8 |
34.33 |
0.2869 |
125 |
18/2.97 |
1/2.97 |
14.90 |
125 |
6.94 |
132.0 |
397.9 |
29.17 |
0.2304 |
160 |
18/3.36 |
1/3.36 |
16.80 |
160 |
8.89 |
169.0 |
509.3 |
36.18 |
0.1800 |
250 |
22/3.80 |
7/2.11 |
21.60 |
250 |
24.60 |
275.0 |
880.6 |
68.72 |
0.1154 |
400 |
54/3.07 |
7/3.07 |
27.60 |
400 |
51.90 |
452.0 |
1510.3 |
123.04 |
0.0723 |
450 |
54/3.26 |
7/3.26 |
29.30 |
450 |
58.30 |
508.0 |
1699.1 |
138.42 |
0.0643 |
500 |
54/3.43 |
7/3.43 |
30.90 |
500 |
64.80 |
565.0 |
1887.9 |
153.80 |
0.0578 |
560 |
54/3.63 |
19/2.18 |
32.70 |
560 |
70.90 |
631.0 |
2103.4 |
172.59 |
0.0516 |
630 |
54/3.85 |
19/2.31 |
34.70 |
630 |
79.80 |
710.0 |
2366.3 |
191.77 |
0.0459 |
710 |
54/4.09 |
19/2.45 |
36.80 |
710 |
89.90 |
800.0 |
2666.8 |
216.12 |
0.0407 |
800 |
72/3.76 |
7/2.51 |
37.60 |
800 |
34.60 |
835.0 |
2480.2 |
167.41 |
0.0361 |
900 |
72/3.99 |
7/2.66 |
39.90 |
900 |
39.90 |
939.0 |
2790.2 |
188.33 |
0.0321 |
