XLPE Insulated SWA Cable/RVMV 0.6/1 kV

Name: XLPE Insulated SWA Cable/RVMV 0.6/1 kV
Brand: Taifa
SKU: 129215761
Availability: InStock

XLPE Insulated SWA Cable/RVMV 0.6/1 kV thumbnail-1

XLPE Insulated SWA Cable/RVMV 0.6/1 kV photo-1

US$ 5 - 9,999 MOQ: 1 Kilometer

Key Specifications

Get Latest Price

Place of Origin:

Henan, China

Brand Name:

Taifa

Model Number:

RVMV 0.6/1 kV

Contact Supplier Request Quote Chat Now

Henan Taifa Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Henan, China

Brand Name Taifa

Model Number RVMV 0.6/1 kV

Insulation Material XLPE

Type Low Voltage

Application Underground

Conductor Material Copper

Jacket PVC

Specifications

good quality with first-class service
qc inspection and ccc certificate
high credit with 30 years experience
low price

XLPE insulated SWA cable/RVMV 0.6/1 kV

XLPE Cable not only has excellent electric character, mechanical character, heat and aging-resistant character, environmental stress-resistant character and chemical corrosion- resistant character, but simple structure, light weight, no restriction by laying drop, and high temperature allowance for long-term working as well.

We can produce XLPE Insulated Power Cable according to GB Standard(China Standard) which is equivalent to the standard IEC60502.We can also design and manufacture special XLPE cable according to the other standards required by the clients.

Rated Voltage,Core Numbers & Nominal Cross-section Area as following Table 2-1

U₀/U_m(kv)

No.of Core

1st class

0.6/1

1.8/3

3.6/6

6/10

8.7/15

12/20

18/30

21/35

2nd class

1/1

3/3

6/6

8.7/10

12/15

18/20

26/35

1 Core

Section

area(mm2)

1.5-800

25-800

35-800

50-800

2 Core

Section

Area(mm2)

1.5-185

3 Core

Section

area(mm2)

1.5-400

25-400

35-400

50-400

4 Core

Section

Area(mm2)

2.5-400

25-400

5 Core

Section

area(mm2)

2.5-400

25-400

Table 2-2 Type Description & Application Occasion of cable

Type		Description	Application n
Cu	Al	Description	Application n
YJV	YJLV	XLPE insulation PVC sheath power cable	To be laid indoors, in tunnel, cable furrow or pipe, the cable couldn't bear mechanical force outside
YJY	YJLY	XLPE insulation PE sheath power cable
YJV22	YJLV22	XLPE insulation, steel tape armor, PVC sheath power cable	To be laid underground, the cable could bear certain mechanical force, but it couldn't bear great pulling force.
YJV23	YJLV23	XLPE insulation, steel tape armor, PE sheath power cable
YJV62	YJLV62	XLPE insulation, have no the magnetism steel tape armor, PE sheath power cable
YJV32	YJLV32	XLPE insulation, thin steel-wire armor, PVC sheath power cable	Be applicable to the well, water inside and fall in the bad soil, the cable cans bear the equal dint outside the machine with pull the dint .
YJV72	YJLV72	XLPE insulation, have no the magnetism thick steel-wire armor, PVC sheath power cable
YJV42	YJLV42	XLPE insulation, thick steel-wire armor, PVC sheath power cable	Be applicable to the well, underwater with the bottom of sea, the cable cans bear the bigger pressure with lead to pull the dint.
Special Note	The single-core magnetism material packs the cable is not suitable for to use for the AC power supply back track, the necessity hour eligibility uses the single-core 62 or 72 type pack the cable. Disallow the cent to cross the magnetism piping mutually when single-core cable establish, the in order to prevent results in the descent that cable transport electric current ability.

Henan Taifa Cable Co., Ltd. was established in 1980, as a Chinese top manufacturer of power cables and wires. Besides CIS certificate, SGS certificate, SONCAP certificate and others, we have also attained ISO9001, ISO14001 and CCC certifications.

We obtained CIS certificate, SGS certificate, SONCAP certificate and others, we have also attained ISO9001, ISO14001 CCC certifications and others.

Sincerely looking forward to your attention, more specification details about this type or others please contact me freely; maybe I’ll give you a big surprise.
