2012 HOT SALE cnc transmission tower machine CNC Angle Marking&Drilling Production Line(APL-2532) CNC Angle line

Specifications

1.India working Office
2.CE&ISO9001 Certificate
3.Factory built in 1991
4.One Year Product Warranty

2012 HOT SALECNC Angle Marking&Drilling Production Line

ITEM: APL-2532





Equipment Features:



◊ The machine is a professional automatic equipment for typing, marking and drilling of angle steel.

◊ With CNC and servor motor it can get high efficiency and steady precison.

◊ The main hydraulic, pnuematic and electrical elements are imported

◊ Easy program can use the automatic data from software directly. Computer with English display and  can show work piece figure,easy for operation.



Advantages:



1. Rotation speeds of all spindles are stepless adjustment realized by frequency converter, feeding speed is also stepless adjustment realized by flow control valves. Rapid feed, working feed and rapid back of drilling spindles can be automatically converted.
2. There is a marking unit in the drilling line, Marking stadia can be present conveniently.
3. Hydraulic system serves for marking, pressing of workpiece, drilling feed. All main components are of imported from abroad. Cooling system with automatic circling is adopted to prolong the life of drills.
4. Control system includes many units, such as host computer, CNC system, AC servo motor, PLC, monitoring switch for outside etc. Machining program can be generated automatically. In computer as long as operator inputs the dimensions of workpiece, which can be conveniently stored, called up, displayed and communicated according to different workpieces.

Main Technical Specifications



Model		APL-2532
Function		Drilling & Marking
Angle Size	Min. (mm)	140x140x10
	Max.(mm)	250x250x32
Material		Q235A or 16Mn
Nominal Marking Power(kN)		1040
Number of Character Group		1
Character Dimension(mm)		14x10x19
Drill for each Leg		3
Main Shaft Speed(r/min)		180~560(stepless adjustable)
Diameter of Drilling Hole(mm)		17.5~40
Drilling Main Axis Travel(mm)		40~240
Number of CNC Axis		3
Angle Steel Feeding Speed(m/min)		40(stepless adjustable)
Overall Dimensions(m)		29x8.9x2.5
Net Weight(kg)		Appr.16500kg



































Fully ISO Certificate Approved, for more information about the certificate, please feel free to contact me~~
