Specifications
1.CNC Angle line for power transmission2.good rigity compact structure
3.Important parts all imported
4.CNC servo motor
Hot !CNC angle line marking punching cutting machine APL-1412
Features The production lines professional automatic equipment for marking,punching and shearing of angle steel
of electric power and telecommunication angle steel tower.
materialoading unit, feeding unit, main body, finished products conveyor unit, hydraulic power unit,and electric
control unit.
Advantages 1) Good rigidity, compact structure, optimal workpiece arrangement and high using rate of workpiece. 2) Marking, punching and shearing are automatically operated with high efficiency.
3) Friendly computer interface can show workpiece’s figure, easy for operation.
4) Easy programming,only need to input the data of workpiece,including size,hole diameter, stadia accuracy and
quantity. Or use the programming data created by lofting software.
5) Many solutions are adopted to resolve problems such as infeeding difficulty and stadia accuracy error which are
caused by angle steel deformation.
6) With CNC and servo motor achieves it high efficiency and stable working accuracy. 7) The key hydraulic pneumatic and electrical elements are all imported from Germany, Japan, and South Korea etc.
Technical datas
Model | APL-2020 | APL-1412 |
Angle size | 63×63×4~ 200×200×20 | 40×40×3~ 140×140×12 |
Max. punching capability Diameter×Thickness | Φ26×20 | Φ26×20 |
(KN)Nominal punching force | 1000 | 600 |
(KN)Marking force | 700 | 700 |
(KN)Shearing force | 1400 | 900 |
(m)Max. length of workpiece | 14 | 12 |
(m)Max. length of finished product | 10 | 10 |
No. of punches of every side | 3 | 2 |
No. of character group | 4 | 4 |
(mm)Dimensions of character | 14×10×19(According to demands of customers | |
Number of CNC axis | 3 | |
Shearing mode | (Doubel-blade Shearing) | |
(m/min)Feeding speed | 30 | 60 |
Processing precision | Meeting the requirement of GB2694-81 | |
Programming model | Keyboard enter, RS232interface enter, CAD | |
(m)Overall dimensions | 32×7.5×2.35 | 25×6.5×2.2 |
(t)Net weight | 20 | 12 |
The pictures of the machine
Guarantee and After sales service:
1. The seller will supply free online technical service via email, fax, telephone etc.
2. The seller will arrange free training program for the buyer’s staff at the seller’s factory in China, the buyer should bear
his staff’s personal expense in China (i.e. air tickets, allowance, hotel and accommodation …). The training program will
last around 1 week.
3. The seller will supply on-site install, commissioning and training service also upon the buyer’s requirement. The buyer should bear all the on-site service cost, including the Visa cost, international air tickets and the technician’s allowance (50.00USD per day), and
the local transportation cost, hotel and accommodation.
