Specifications
1)China Manufacturing high speed drilling Machine2Factory built in 1991
3)ISO9001:2008,CE
4)Product in Stock
China Manufacturing Machine CNC Angle Steels High Speed Drilling Machine
This Machine is popular for processing Tower Factory
1.High quality, Fair Price, Fast Delivery.
2.OEM Service, Trail Order
3.The Color, The logo, The package according to your request,
4.We are the Manufacturer,We have many engineers for the solutions for the new market to keep the trend of the world.
Jinan Liaoyuan Machine Co.,Ltd is a fast growing company dedicate to offer Iron tower and steel struction equipment and Win-Door Machinery
Machine Features
1) The machine is professional automatic equipment for marking and drilling of angle steel.
2) With CNC and serve motor it achieves high efficiency and stable working accuracy.
3) The main hydraulic,pneumatic and electrical elements are all imported from Germany,Japan Italy South Korea, etc.
4) Easy programming. The operator can use the automatic data from software directly. Friendly Computer interface can show workpiece’s figure, easy for operation.
Machine Advantages
1) Rotation speeds of all spindles are stepless adjustable realized by frequency converter. Feeding speed is also stepless adjustable realized by flow control valves. Rapid feed, working feed and rapid back of drilling spindles can be automatically converted
2) There is a marking unit in the drilling line. Marking stadia can be preset conveniently.
3) Cooling system with automatic circling is adopted to prolong the life of drills.
4) Machining program can be generated automatically in computer as long as operator inputs the dimensions of workpiece which can be conveniently stored, called up, displayed, and communicated according to the different workpieces.
5) Direct transfer of CAD/CAM.
6) Equipped with Self-diagnostic function.
Main Technical Specifications
Model Number |
APL-2532 |
Function |
Drilling & Marking |
Angle size |
140×140×10~250×250×32mm |
Material |
Q235A or 16Mn |
Nominal marking force |
1040KN |
No. of character groups |
1 |
Dimension of character |
14×10×19 |
Number of drills on each side |
3 |
Main shaft speed |
180-560/(r/min)(stepless adjustable) |
Diameter of drilling hole |
Φ17.5~Φ40(mm) |
Drilling main axis travel |
40—240(mm) |
Number of CNC axis |
3 |
Angle steel feeding speed |
40m/min |
Machine Images
Usually we deliver the machines in 40 ' container with nude packing
Liaoyuan Machine established in the 1990s. Liaoyuan Machine is located in Jinan city of China, originally started to make pvc/aluminum window & door machine from 1991 year. We are the only one chinese company who enjoy the capacity from spare parts casting, machine design, technology innovation and machine assembling, which are totally achieved at your factory.
In more than 20 years of development, Liaoyuan Machine has energetically explored the resource development space to realize rapid development. Nowadays, Liaoyuan Machine has been developed into a large machine tool production enterprise with a land area of four hectares, a workshop area of 15,000 square meters, more than 350 employees, more than 100 sets of professional production equipment and annual designing and production ability of more than 700 sets of machine tools. In 1998, Liaoyuan Machine was granted the authorized import & export license by the Commission of Foreign Trade and Economic Cooperation of China.
Jinan Liaoyuan Machine Co.,Ltd Attend Annual Machinery Exhibition
Customers all over the world visited Jinan Liaoyuan Machine Co.,Ltd
Fully ISO Quality Management System Approved, For more informaiton about
the certificate,please feel free to contact me!!!
