Help CenterLow Cost Hollow Block Making Machine Price of HY-QT8-15, Used Concrete Block Making Machine
Related Products
-
The Most Popular Style in 2013 of Block Making Machine, Small Block Making MachineUS$ 29,000 - 35,000MOQ: 1 Set -
2013 High Competitive QT6-15 Automatic Manual Hollow Block Making Machine,fly Ash Brick Making Machine,cement Block MachineUS$ 40,000 - 70,000MOQ: 1 Set
-
2012HOT SALE QT8-15 Fully-automatic Cement Brick Making Machine Industries Machines, Hollow Block Making Machine PriceUS$ 35,000 - 41,000MOQ: 1 Set
-
2014 New Products QT8-15 Automatic Cement Brick Making Machine From Famous China SupplierUS$ 35,000 - 41,000MOQ: 1 Set
-
2013 the Best Price QT6-15 Automatic Manual Hollow Block Making Machine,concrete Block Factory for SaleUS$ 40,000 - 70,000MOQ: 1 Set
1,full automatic block machine
2,fly ash brick making machines
3.block making machine
4.used concrete block making machine
:
| Cycle time: 15-20(s) | Vibration Type: hydraulic vibration |
| Total Power: 38.1kw | Vibration Force: 95(KN) |
| Vibration Frequency: 3800-4500(times/sub) | Gross Weight: 10500(kg) |
| Pallet size : 1100×700×25mm | Machine Size: 9800*3600*2800mm |
| Rated Pressure: 31.5(mpa) | |
| Block Specification : | Production per shift (8 hours) |
| 390×190×190mm 8(pcs) | 11,520-15,360(pcs) |
| 240×115×53mm 40(pcs) | 57,600-76,800(pcs) |
| 240×115×90mm 21(pcs) | 30,240-40,320(pcs) |
| 200×100×60mm 28(pcs) | 40,320-53,760(pcs) |
2,Main Technical Specifications:
A. Intelligence PLC touch screen and pure electrical element (high automatic and easy to operate ) ;
B. Arch breaking type of rapid feeding device (better feeding multi-hole bricks with better uniformity) ;
C. Forming production faster and with higher compactedness ;
D. High-heat treatment special technology (to make the mould more durable and more firm) .
Raw materials :crushed stone ,sand, cement, many types of industrial waste, like, lime, fly ash, slag, coal gangue, gravel, perlite , etc.
Multiple uses. It can produce all types of standard building blocks by changing mould.
A, Multi-holes block and hollow block ;
B, Ceramsite heat preservation block;
C, Composite heat preservation concrete block.
3.Clay Brick Sizes and capacity:
Brick |
Sizes |
Output/ mould |
Output/Shift(8hours) |
picture |
Blocks |
390x190x190mm |
8 |
11,520-15,360 |
|
Porous bricks |
240x115x90mm |
21 |
30,240-40,320 |
|
Interlocking block |
200x100x60mm |
28 |
40,320-53,760 |
|
Solid bricks |
240x115x53mm |
40 |
57,600-76,800 |
|
4. Production Flow Introduction
5.Products display:
6.Block and brick Sample:
