Help Center2013 High Competitive QT6-15 Automatic Manual Hollow Block Making Machine,fly Ash Brick Making Machine,cement Block Machine
Related Products
-
2012HOT SALE QT8-15 Fully-automatic Cement Brick Making Machine Industries Machines, Hollow Block Making Machine PriceUS$ 35,000 - 41,000MOQ: 1 Set -
2014 New Products QT8-15 Automatic Cement Brick Making Machine From Famous China SupplierUS$ 35,000 - 41,000MOQ: 1 Set
-
2013 the Best Price QT6-15 Automatic Manual Hollow Block Making Machine,concrete Block Factory for SaleUS$ 40,000 - 70,000MOQ: 1 Set
-
Moving Block Machine , QT8-15 Fully-automatic Cement Brick Making Machine Industries Machines,US$ 35,000 - 41,000MOQ: 1 Set
-
Full Automatic Cement Brick Making Machine From China SupplierUS$ 53,000 - 72,000MOQ: 1 Unit
1.used concrete block making machine
2.full automatic block making machine
3.fly ash brick making machine
1.Main technical parameters:
Cycle Time |
15-20 Sec |
Vibration Type |
hydraulic vibration |
Total Power |
37.4kw |
Vibration |
68(KN) |
Vibration Frequency |
3800-4500(times/sub) |
Gross Weight |
7500(kg) |
Pallet Size |
880×680×20(mm) |
Machine Size |
9450×3300×2700mm |
Rated Pressure |
25(mpa) |
Stacking Machine Power |
2.25kw |
2.Main technical Specifications:
1. It consists of mechanic, electricity and hydraulic in one machine, and it runs automatically in circulation each procedure is interlocked, and the pressure is automatically assigned.
2. Easy to change mechanical action according to different raw materials.
3. Fault self-diagnosis, comport for remote control guarantees technical support and maintenance.
Raw materials :crushed stone ,sand, cement, etc; many type of industrial waste, like, lime, fly ash, slag, coal gangue, gravel, perlite, ect. .
multiple uses, it can produce all type of standard building blocks by changing mould.
1,Multi-holes block and hollow block .
2,Ceram site heat preservation block.
3,Composite heat preservation concrete block
The above production come with good heat preservation performance, and it meets the new national energy conservation policy.
Cycle Time |
15-20(s) |
Total Power |
33.6(kw) |
Vibration Type |
hydraulic vibration |
Vibration Frequency |
3800-4500(Times/sub) |
Machine Dimension |
9450*3300*2700(mm) |
Pallet Size |
850×680×20(mm) |
Vibration Force |
68KN |
Gross Weight |
7500(kg) |
Production/Mould |
Productions/8hours(pcs) |
||
6pcs/m (390x190x190mm) |
8,640---11,520 |
||
15 pcs/m (240x115x90mm) |
21,600---28,800 |
||
30 pcs/m (240x115x53mm) |
43,200---57,600 |
||
18-21 pcs/m (200x100x60mm) |
About 27,000 |
||
3. Production Process:
4.Production Flow Introduction:
5.Block & Brick Sample:
6. Product Show:
7. Customer Production Field:
