Blue Non-contact Ultrasonic Distance Sensor ModuleUltrasonic SensoDYP-ME007TX Ultrasonic Ranging Detector Module Distance Sensor

Specifications

This sensor provides a easy method for distance measurement and is widely used in robotics applications,which is with a 3cm to 4m detecting range, it is widely used in robotics applications and is also useful in security systems or as an infrared replacement.

Description:

1 This ultrasonic sensor is a non-contact distance measurement module;

2 Electronic brick compatible interface and breadboard friendly;

3 Dual transducer, three-pin on board (VCC, OUT and GND);

4 Designed for easy modular project usage with industrial performance;

Specifications:

1 Detecting Range: 3cm-4m (1.2-157.5 inch);

2 Supply Voltage: 5V;

3 Current Consumption: 15mA;

4 Best in 30 degree angle;

5 Ultrasonic Frequency: 40KHz;

6 Dimension: 1.8 x 0.8 x 0.5 inch / 4.6 x 2 x 1.3 cm (pins not included);
