Specifications
This sensor provides a easy method for distance measurement and is widely used in robotics applications, which with a 3cm to 4m detecting range, it is widely used in robotics applications and is also useful in security systems or as an infrared replacement.
Description:
1 This ultrasonic sensor is a non-contact distance measurement module;
2 Electronic brick compatible interface and breadboard friendly;
3 Dual transducer, three-pin on board (VCC, OUT and GND);
4 Designed for easy modular project usage with industrial performance;
Specifications:
1 Detecting Range: 3cm-4m (1.2-157.5 inch);
2 Supply Voltage: 5V;
3 Current Consumption: 15mA;
4 Best in 30 degree angle;
5 Ultrasonic Frequency: 40KHz;
6 Dimension: 1.8 x 0.8 x 0.5 inch / 4.6 x 2 x 1.3 cm (pins not included);
