This ultrasonic sensor provides a easy method for distance measurement, with a wide detecting range. Ultrasonic transducers are widely used in fields like industrial, auto, teaching and robots, etc. This ultrasonic sonsor's maximum detecting distance is about 8m. It's really a powerful ultrasonic transducer module.
Description:
1 This ultrasonic sensor is a non-contact distance measurement module;
2 Small blind zone;
3 Long detecting distance, high resolution;
4 Low power comsumption;
5 Designed for easy modular project usage with industrial performance;
Specifications:
1 Detecting Range: 8cm-8m ;
2 Supply Voltage: 5V DC(default), DC6-12V (optional);
3 Standby current : <10mA;
4 Instantaneous current of emission : about 250mA;
5 Distance output of serial : Precision is 0.5cm, resolution is 0.1cm ;
6 Interface Mode: PWM and UART serial output (default), RS485(optional);
7 Ultrasonic Frequency: 50KHz;
8 Detection Angle: 15 degrees (-6dB);
9 Working cycle : 80ms;
10 Working Temperature: -20°C to +75°C;
11 PCB Size: Approx. 50 x 50mm / 2 x 2 inch;
