This ultrasonic sensor is a non-contact distance measurement module which is compatible with the Grove system. It’s designed for easy modular project usage with industrial performance.
Description:
1) The modules includes ultrasonic transmitters, receiver and control circuit;
2) Its stable performance and high ranging accuracy make it a popular module in electronic market;
3) There are 5 pins out of the module, VCC, Trig, Echo, GND and OUT;
4) Best performance in 30 degrees angle;
5) Electronic brick compatible interface;
6) Dual transducer;
7) Arduino library ready;
Specifications:
1) Voltage: DC 5V;
2) Current: 15mA;
3) Ultrasonic Frequency: 40K Hz;
4) Maximal Range: 500cm;
5) Minimal Range: 2cm;
6) Resolution: 1cm;
7) Trigger Pulse Width: 10μs;
8) Dimension (L x W x H): Approx. 44 x 20 x 18 mm;
