Specifications
This transmitter is suitable for any place where needed temperature and humidity measurement to monitor.Description:
DYP - TH630F temperature and humidity transmitter is suitable for intelligent building,telecommunications room,central air condition system,archives,library,clean room,workshop,agricultural greenhouses,storage,super market,cold room,freezer and other place where needed temperature and humidity measurement to monitor.
Features :
1) This serie of SHT integrated temperature-humidity sensor is imported from Switzerland,which with features of reliable performance, high precision and little drift;
2) Large screen LCD synchronously displays the actual value of temperature and humidity;
3) Substructure and principal part could be separated,it’s easy to install and maintain;
Technical parameters:
1) Supply voltage: DC 9V - 24V;
2) Electric current: < 10mA;
3) Measurement range: Temperature: -20°C~70°C; Humidity: 0~100%RH;
4) Measurement accuracy: Temperature: ±0.5°C; Humidity: ±4%RH;
5) Display resolution: Temperature: 0.1°C; Humidity: 0.1%RH;
6) Interface type: output switch, normally open and will be short circuit output when receive alarm. You could set the alarm freely by relay 1 and relay 2 in menu bar, which includes the up and down temperature alarm limited, both (up and down) also could be set as an alarm. temperature alarm hysteresis is 1.5°C. Humidity alarm hysteresis is 3%.
7) Installation way: indoor is wall-mount and ceiling installation;
8) Dimension: 82mm X 82mm X 29mm;
9) Weight: approx. 200g;
Note:
1) The joint of trunking ports and sensor substructure need to be used the PVC terminals to transit when you install this sensor. In order to ensure the trunking and sensor could be in axis of the same line, we suggest you'd better to install the substructure firstly then nail the trunking.
2) The horizontal distance from sensor to air condition air distributor should be more than 1.5 m, and to the ceiling air distributor should be more than 0.5m.
3) In order to prevent the isolation floor of cold air through the trunking to impact the actual measurement,it should be added the PVC terminals at the upper port of trunking or install the sensor in side of the trunking.
