Help Center250W Solar Module Solar Panel With TUV IEC CCC Certificates
Related Products
-
(2014 China OEM)130w Solar Panel From Sungold ManufacturersUS$ 0.7 - 0.8MOQ: 100 Pieces -
China Supplier MS Monocrystalline 250W Solar Panel MS-M250(96)US$ 1.6 - 2.2MOQ: 100 Pieces
-
China Supplier Yueqing Ruixin Group Photovoltaic Module Mono 250 Watt 60 Cells Solar Panel With TUV CE ROSH Best Price per WattNegotiableMOQ: 100 Pieces
-
300W Mono Solar PanelUS$ 0.4 - 0.48MOQ: 6000 Watts
-
300W Poly Solar PanelUS$ 0.4 - 0.48MOQ: 6000 Watts
Specifications
A-grade cell high efficiency 5W-300W PV solar panel
1.Higher conversion efficiency
2.quick delivery
3.Excellent in quality
Specifications
FEATURES
`Long Service Life
`High Efficency Solar Cells
`Special Aluminum Frame Design
`High Transmission,Low Iron Tempered Glass
`Advanced Cell Encapsulation
APPLICATIONS
`Solar power stations
`Rural electrification, Small home power systems
`Power supply for traffic, security, gas industry
`12V and 24V battery charging system
`Other industrial and commercial applications
| ELECTRICAL CHARACTERISTICS | ||||||
| Model Number | KM(P)230 | KM(P)235 | KM(P)240 | KM(P)245 | KM(P)250 | |
| Maximum Power as per STC | Pmax(W) | 230 | 235 | 240 | 245 | 250 |
| Power Tolerance | % | ±3% | ||||
| Maximum Power Voltage | Vm(V) | 30.48 | 30.6 | 30.66 | 30.98 | 31.29 |
| Maximum Power Current | Im(A) | 7.6 | 7.68 | 7.83 | 7.91 | 7.99 |
| Open Circuit Voltage | Voc(V) | 36.6 | 36.72 | 36.84 | 37.38 | 37.5 |
| Short Circuit Current | Isc(A) | 8.17 | 8.23 | 8.32 | 8.42 | 8.5 |
| Maximum System Voltage | VDC | 1000 | ||||
| Cell Efficiency | % | 15.8 | 16.1 | 16.4 | 16.8 | 17.1 |
| Module Efficiency | % | 14.1 | 14.4 | 14.7 | 15.0 | 15.3 |
| Cells per Module | Pcs | 60 | ||||
| Cell Type | Polycrystalline silicon | |||||
| Cell Size | mm | 156 x 156 | ||||
| Bypass Diodes | Pcs | 12Amp, 6 pcs | ||||
| Max. Series Fuse Rating | A | 15A | ||||
| Temperature coefficient of Isc | %/°C | 0.05 | ||||
| Temperature coefficient of Voc | %/°C | -0.35 | ||||
| Temperature coefficient of power | %/°C | -0.47 | ||||
| NOCT- Nominal operating cell temperature | °C | 47 ± 2 | ||||
| Operating Temperature | °C | -40 ~ +85 | ||||
| MECHANICAL CHARACTERISTICS | ||||||
| Dimensions | mm | 1650 x 990 x 50 | ||||
| Weight | Kg | 19.8 | ||||
| Type of Junction Box | TUV certified, IP65 | |||||
| Cable Type, Diameter | TUV certified, 4mm2, 90 cm in length | |||||
| Connector | compatible to Type 4 (MC4) | |||||
| Tempered Glass | 3.2 mm, high transmission, low iron | |||||
1 Our loyal purport: Based on sincerity! Serve the first!, your trustworthy parter
2 Devoted in the power transmission and distribution since 1995, having lots of experienced
engineer and workers
3 We are able to contract foreign project obtained the qualification certificate
1. Which payment terms do you accept?
a.The payment term varies with different price level and total rate of each contract.
The following are most common terms:
b. 30% T/T down payment, the balance before you picking up the goods.
c. 100% L/C at sight.
d. 30% T/T down payment, the balance against 100% L/C at sight.
2. What is your MOQ?
You are advised to please confirm it with us directly as it’s based on different Solar Panel type.
Usually it’s 100 Piece for Solar Panel.
3. What about the lead time for our cable product ?
The lead time according to the your order's quantity.Usually our lead time is 10 - 30 wrking days.
4. What about our product's package ?
our product's package usually is neutro-packing
For more information on detailed cable characteristics please call 86 577 57185601
Or email us your request for design Solar Panel.
