Specifications
A-grade cell high efficiency 5W-300W PV solar panel
1.Higher conversion efficiency
2.quick delivery
3.Excellent in quality
(2014 China OEM)130w solar panel from sungold manufacturers
Quality and Safety
1). solar panel made of Germany manufactured Bosch solar cell.
2). Management Certification: ISO 9001:2008 TUV CE RoHS ISO 14001:2004
3). Factory directly supply
4). Perfect quality and long lifespan
5).5-year limited product warranty
6).25-year linear power warranty
7).12 years at 90% of minimal rated power output and 25 years at 85% of minimal rated power output
8).25 years quality warranty
Efficiency
•Low voltage-temperature coefficient allows higher power output at high-temperature condition
•High efficient, high reliable solar cells ensure our product output stability
Material
1.Solar cell-conversion efficiency of solar cell: 24%-17%
2.Front glass-3.2mm, high transmission, low iron, tempered glass
3.EVA-excellent anti-aging resistance
4.TPT-hot seal made of flame resistance
5.Flame-reinfored anodixed aluminum flame
6.Junction box-Ip54 rated and Ip65 rated, high quality, with diode protection
Benefits
•Manufactured in an ISO 9001:2008 certified plant
•High efficiency, high safety, high reliability
•Output power tolerance of +/-3%
•25-year limited warranty on power output, 5-year limited warranty on materials and workmanship
Product parameters
| Electrical Characteristics | |
| Model | SGM-130w |
| Cells size (mm): | 156*126.3 |
| Cells per module: | 36pcs |
| Module size (mm): | 670*1205*35cm |
| Power tolerance: | +/-3% |
| Nominal peak power(WP): | 130w |
| Nominal voltage(V): | 17.8 |
| Nominal current (A): | 7.30 |
| NOCT: | 45+/-2degree |
| Voltage temperature coefficient: | -0.33%/degree |
| Current temperature coefficient: | +0.05%/degree |
| Power temperature coefficient: | -0.23%/degree |
| Open circuit voltage (Voc): | 22.3 |
| Short cirsuit current(Isc): | 7.89 |
| Conversion efficiency: | 18.44% |
| Operating temperature: | -40 to+85degree |
| Max system voltage: | 1000V DC |
| Surface Maximum Load Capacity | 60m/s(200kg/sq. m) |
| Cell power | 4.16w |
1 Our loyal purport: Based on sincerity! Serve the first!, your trustworthy parter
2 Devoted in the power transmission and distribution since 1995, having lots of experienced
engineer and workers
3 We are able to contract foreign project obtained the qualification certificate
1. Which payment terms do you accept?
a.The payment term varies with different price level and total rate of each contract.
The following are most common terms:
b. 30% T/T down payment, the balance before you picking up the goods.
c. 100% L/C at sight.
d. 30% T/T down payment, the balance against 100% L/C at sight.
2. What is your MOQ?
You are advised to please confirm it with us directly as it’s based on different Solar Panel type.
Usually it’s 100 Piece for Solar Panel.
3. What about the lead time for our cable product ?
The lead time according to the your order's quantity.Usually our lead time is 10 - 30 wrking days.
4. What about our product's package ?
our product's package usually is neutro-packing
For more information on detailed cable characteristics please call 86 577 57185601
Or email us your request for design Solar Panel.
