SMICO New Products Innovation 160A Isolating Single Phase Fuse Switch Disconnector
| Voltage | 500V |
| Insulation level | 1000V |
| Frequency | 50/60Hz |
| Operational current with fuses | 160A |
| Operational current with blades | 250A |
| Installation category | AC22 |
| Short lasting Current(1s) | 3,2KA |
| Dynamic current(crest) | 25KA |
| Interruption capacity | 100KA |
| Minimum mechanical life(operation) | 1000 |
| Weight | 600G |
| Protection range | IP23 |
The APDM160 fuse swith it is used either as an operation or protection device for LV lines. It is designed to be used with NH 00 size fuses offering a maximum of 160 Amps of line protection without blades.
In case blades are used, the maximum switching load would be 250A. It is manufactured in reinfored fiberglass polyamide and fulfills all the necessary requirements for outdoor installation and operation.
In the APDM 160C model the connection is made with connectors suitable for aluminum and copper conductors with a section range between 16 and 95 mm2 (5-4/0 AWG).
The APDM160 model can also be connected with terminals lugs and both models can be installed with single phase or three phase opening.
They have special sockets to obtain a compact set.
The switch is operated from the ground with an operating rod and also hasan indicator to show if the fuse is placed. It can be sealed with security ties
It also has a led to show the fusion of the fuse.
1.Packaging:
Export Carton,or as your request.
2.Shipping Methods:
By air or by sea(FOB port:Shanghai/Ningbo),by express (DHL,UPS,TNT,FEDEX).
1. Your inquiry related to our product & price will be replied within 24 hours.
2. Well-trained & experienced staff are to answer all your inquiries.
3. Customized solution & perfect after-sale service.
4. Our advantage:
A.Competitive price B.Good quality
C.Timely delivery D.New model launch weekly
E.Own manufacturing F.Own quality control
1.Manufacturer With Competitive Price And High Quality.
-We are the manufacturer with direct sale price and high quality to help you open the markets which located in Wenzhou City, Zhejiang Province, China. Welcomed to visit our company.
2.OEM/ODM.
-We are the manufacturer with a brilliant team work team work.
3. Usual Payment Term.
-We accept terms of T/T in advance, L/C, Western Union and others. Any question, please ask us!
4. Warranty Time.
-1.5 years. Any problem of the quality is changed by your next order free.
5.Free Sample.
-Yes, we provide small products to check quality for you, just you pay the express fees.
