Photo Album 4-in-1 Machine Gluing,trimming,laminating and Hot Pressing
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Machinery & Hardware
Packaging Type:
Film
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Album Polishing And Gilding MachineUS$ 1 - 1,760MOQ: 1 Set -
2014 New Design Photo Album MakerUS$ 1,000 - 3,500MOQ: 1 Set
-
DHY-A 10 in 1 Making Photo Album and Menu MachineUS$ 1 - 50MOQ: 1 Set
-
All in One Machine, Multifunction Album Making MachineUS$ 1,000 - 3,333MOQ: 1 Set
-
For Photo Album , Menu Making All-in-one Machine (DHY-A)US$ 1,000 - 3,333MOQ: 1 Set
Condition
New
Application
Other, Machinery & Hardware
Packaging Type
Film
Packaging Material
Paper
Automatic Grade
Semi-Automatic
Driven Type
Electric
Voltage
AC220v/50hz
Power
1kw
Place of Origin
Guangdong, China
Brand Name
HY
Model Number
SZHY-A
Dimension(L*W*H)
1065*890*1215mm
Weight
180kg
Certification
CE
After-sales Service Provided
No overseas service provided
Four functions including gluing, trimming, lamination,
Flattening for the album
Shorten the drying time, not change shape
Enlarge flattening capacity, unform temperature
Small space, continueous operation, increasing effciency
Power Supply: AC220V/110V/50Hz(single phase)
| specification | SZHY-A |
| gluing width | 650MM |
| gluing thickness | 70MM |
| gluing speed | 20m/min |
| Power/rate of work | AC220V/50HZ/100W |
| Trimming length | 540MM |
| Trimming thickness | 70MM |
| Trimming way | pneumatic |
| flattening height | 180MM |
| flattening length | 680MM |
| flattening width | 520MM |
| flattening way | pneumatic |
| Max working area | 720MM |
| Max working thickness | 20MM |
| Speed | 15m/min |
| Machine dimension | 1065*890*1215mm |
