Specifications
1. 32KB Flash, 4KB RAM,low cost module CC1110
2.Central frequency is 470MHz
3.Frequency bands :470 more or less than 5MHz
Features
· Central frequency is 470MHz, Frequency bands :470±5MHz
· Programmable output power up to +20dBm for all supported frequencies,
the communication distance is above 800m in sight .
· High receiver sensitivity down to -110dBm(at 2.4Kbps data rate)
· Programmable baseband modulator with GFSK/2-FSK/ASK/OOK/MSK
· Programmable data rate 1.2~500Kbps
· CRC computation and CRC check sum to keep data transmit reliable
· Support carrier sense and digital RSSI output
· Integrated industrial 8051 MCU, support IAR.
· 32KB Flash, 4KB RAM, Optional integrated EEPROM(2~64KB)
· 7-12bit ADC with up to eight inputs, 128-bit AES security coprocessor, Powerful DMA functionality.
· Two USARTs, I2S interface, 4 timers, 21 PGIO pins.
· Low current consumption with receive mode <22mA, transmit mode at +20dBm output power <100mA
· Low current consumption at power down state <2uA
· Wake-on-radio functionality for automatic low-power RX polling
· Small dimension: 31.5mm×27.0mm×13.1 mm(SMA connector and header included)
· Operating supply voltage: 2.4~3.6V DC
Applications
· Logistics Tracking System, Warehouse patrol, Electronic label.
· Replace RS232 and RS485 in data transmission
· Industrial monitoring and control in data acquisition
· AMR – Automatic Meter Reading
· Home and building automation
· Consumer Electronics products of wireless control
· Wireless alarm and security systems
· Wireless sensor networks
