good at exceedingly fast long range wireless video transmitter receiver

Hardware specification

ATHEROS  AR7240 400MHZ CPU AR9285 RF 32MDDR 8M FLASH

Frequency Bands

2.4GHz;5MHZ,10MHZ,20MHZ,40MHZ

RF Output Power

26dBm

Modulation Mode

DBPSK,DQPSK,CCK,OFDM,16-QAM,64-QAM

Sensitivity

150M:-68dBm@10% PER;

130M:-68dBm@10% PER

108M: -68dBm@10% PER

54M: -68dBm@8% PER

11M: -85dBm@8% PER

6M: -88dBm@8% PER

1M: -90dBm@8% PER

Data and operating parameters

Automatic
rate selection

802.11n:6.5-144.44Mbps

802.11b:11/5.5/2/1Mbps

802.11g:108/54/48/36/24/18/12/9/6Mbps

Standard

IEEE802.11n,IEEE802.11g,IEEE802.11b,IEEE 802.3u,IEEE 802.3af

Support Protocols

 CSMA/CA,TCP/IP,IPX/SPX,NetBEUI,DHCP,NDIS3,NDIS4,NDIS5

Size and environmental

Environmental

Physical performance

Weight

0.6kg/0.7kg(packd)

Operation Temperature

-30~65°C

Size

170*115*30mm

Storage Temperature

-50~80°C

Packing

242*233*60mm

Storage Humidity

≤95%(non-condensation)

Management

Web management

Yes

SNMP MIB

Yes

Telnet

Yes

Security

MAC control

Yes

 encryption

WEP  key 64/128 bits,WPA,WPA2,802.1x

Antenna System

Frequency Band(Mhz)

2400

Polorization

Vertical

Increase Ratio(DBi)

5DB

Model

T125 ver1

Frequency range

2.4Ghz

Transmission Rate

150.Mbps

Power

400MW

Coverage

100m²

Antenna

5dBi
