CE Approved 19" LCD Screen/Monitor Motorized Lift Mechanism for Conference System
Introduction:
Pop up screen lift system is advance hiding equipment designed for audio video system in office furniture. The LCD screen of Pop up lcd screen lift system k could be rising down into the desk and hidden under the office table when unused; Screen inside Pop up lcd screen lift system would be rising up from table automatically by touch switch or remote control and present the workable screen on the desktop if used.
Feature:
1, The panel of LCD lift is aluminum alloy/steel stainless, with aluminum wire drawing process on surface.
2, The monitor lift adopts synchronous orbit lifting principle.
3, Electric LCD Jack works smoothly and quietly. Low noise which less than 30db.
4, Screen Lift provides protecting function of LCD monitors by cutting the electricity off automatically.
5, LCD monitor lift would be adjustable elevation angle of LCD monitor for protecting your eyes from the direct light.
5, Motorized LCD monitor lift is controlled by two big AC motors. One controls opening and closing the panel; one controls lifting the monitor up and down and adjust the angles of the monitor.
6, Control system: Touch Switch on monitor lift panel, RF remote control, RS232 AND rs 485 central control.
Characteristic
1, high quality aluminum alloy finishing with motors
2, A=A strong carton with foam cushion and waterproof film
3, white/black/gold color is available for color selection
4, Power plug and voltage could be changed accordingly.
5, OEM with logo on product and packing is available
6, Customized made is available
7, Quality of LCD Monitor Lift had approved by CE
Application:
Pop up lcd screen lift system is widely used on conference system, like video conference system, tv conference system, financial analyzing system, advanced office system, lecture and training room with conference table& computer desk together.
Parameter:
| Item Series | LCD Monitor Lift |
| Item Model | BLL-19 |
| Style | LCD lift without monitor |
| Products consitute | LCD monitor lift + Remote control |
| Material | Aluminum alloy draw bench panel |
| Panel size | 540*160*5mm |
| Box size | 520*138*625mm |
| Panel thickness | 5mm |
| Lift mount size | 460*80mm |
| Packing size | 61*27*84mm |
| Voltage | 110V,220V,240V |
| Power | 20~25W |
| Tilting angle | 0~15° |
| Single trip time | 30s |
| Color | Silver /Black matt/ Gold |
| Remote distance | 10m |
| Control Way | Touch kep-press/Remote control/ RS485 central control |
Product Drawing:
Professional Service:
1, Any of inquiries will be response within 48 hours
2, Sizable accessories of products for replacement
3, Sample of LCD monitor lift is available.
Warranty:
Study the user’s manual carefully before installation.
All of our products provide 12 months warranty! The warranty period starts from the goods receipt by initial consignee.
Payment:
T/T, L/C, Western Union, Money Gram, Crash is acceptable
Product Pictures:
Pop Up Screen on Conference System:
Boente Other Detail Monitor Lift Product
