Photo/Contact Tachometer DT-2859
Applications:
Photo/Contact Tachometer DT-2859 is used to measure rotative velocity, surface speed, frequency of motor.
Applicable to the product departments of:
*motor, fan, paper-product, chemical fiber, washing-machine, automobile, airplane, steamer etc.
*Series:digital Tachometer,motorcycle tachometer,engine tachometer etc.
Features:
* Multifunctional, one instrument combines PHOTO TACH.(RPM) & CONTACT TACH. (RPM , m / min, ft / min ). It can also be applied tothe measurement of Frequency, Cycle, Pulse Times, Pulse Distance, User-defined Pulse Distance, etc.
* Digital display with no guessing errors.
* Wide measuring range and high resolution.
* The last value / max. value / min. value will be automatically stored in memory.
* The use of durable, long-lasting components, including a strong, light weight ABS-plastic housing assures elegant shape and ease ofuse.
* Use USB data output and RS-232 data output to connect with PC.
* Provide Bluetooth data output choice.
Details:
Measuring Range |
Laser |
2.5 ~ 99,999 r / min |
Contact |
0.5 ~ 19,999 r / min |
|
Surface Speed |
0.05 ~ 1999.9 m / min 0.2 ~ 6560 ft / min |
|
| Frequency | 0.04~1666.65 Hz | |
Resolution |
Rotative Velocity |
0.1 r / min (0.5 ~ 999.9 r / min)
1 r / min (Over 1000 r / min )
|
Surface Speed |
0.01 m / min (0.05 ~ 99.9 m / min)
1 m / min (Over 100 m / min )
Or 0.1 ft / min (0.1 ~ 999.9 ft / min)
1 ft / min (Over 1000 ft / min )
|
|
Accuracy |
± (0.05% n + 1 d) |
|
Sampling Time |
1.0 s (Over 60 r / min ) |
|
Test Range Select |
Automation |
|
Memory |
Max / Min / Last Value |
|
Time Base |
Quartz Crystal |
|
Laser Tach Detecting Distance |
50 ~ 250 mm / 2 ~ 10 inch (Typical), Max. 600 mm / 24 inch |
|
Power Consumption |
80 mA (Testing) |
|
Operating Temperature |
0 ~ 50 °C (32 ~ 122°F) |
|
| Power Supply | 4 x 1.5 V AAA size (UM-4) battery | |
Dimensions |
Main Unit | 140 x 72 x 34 mm ( 5.5 x 2.8 x 1.3 inch) |
| Sensor | Φ 45 x 195 mm ( Φ1.8 x 7.7 inch) | |
Weight |
245 g / 0.540 lb (Not Including Batteries) |
|
Accessories:
Standard Accessories:
1. Main Unit
2. Sensor
3. Carrying Case
4. Operation manual
5. Reflective tape 350mm
6. Cone Adapter(AS35A)
7. Funnel Adapter(AS35B)
8. Surface speed test Wheel(AS35C)
Optional Accessories:
1. USB, RS-232C data cable with software
2. Bluetooth data out put with software
In carton, via ocean/land/air
Quality assurance for one year,and forever maintainence.
