Industrial Wastewater Plant COD Electrolytic Processing Apparatus

Specifications

The COD electrolytic processing apparatus is a device for decomposing the COD components in the liquid

Industrial wastewater plant COD Electrolytic Processing Apparatus





The COD electrolytic processing apparatus is a device for decomposing the COD components in the liquid by electrolysis, to reduce the COD of the solution.





It is possible to decompose refractory organic matter to be processed in the wastewater normal processing is difficult.



COD electrolytic processing apparatus is possible to not only perform the reduction of the COD is used alone, is introduced into the waste water processing facilities existing. For example, introducing the device before biological treatment, and processed readily degradable substances to decompose refractory organic matter by electrolysis, and then to the biological treatment. In this way, you can reduce the burden on the biological treatment, to improve the processing efficiency as overall wastewater treatment facility.

If a situation COD raises constantly by circulating water is used, we will introduce a COD electrolytic processing apparatus. Consequently, it is possible to maintain the COD to prevent rise predetermined value or more.















Basic structure of COD electrolytic processing apparatus













Circulate and stir the waste water of electrolytic processing tank, applying a current to the electrolytic processing electrode. As a result, COD components in the waste water is oxidative decomposition by contact with the electrode, it is possible to reduce the COD in the waste water.





Electrode is a special insoluble electrode for electrolytic processing.



Through the COD electrolytic treatment equipment, we do not have to worry about the electric shock etc. for use in low voltage conditions.



There is also that you use additives for electrolytic processing depending on the state of the waste water.



















ISO





Other Products



Ultra Electrolyzed Alkaline Water Clean Shu! Shu!	Paint detackifier for any problems about paint
Alkaline detergent Fryer pack for tough oil stains
