Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GOLDSHINE
Model Number:
GS328
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
GOLDSHINE
Model Number
GS328
Usage
Pressure Sensor
Theory
Resistance Sensor
Output
Other, Analog sensor/Digital sensor
Product Characteristics:
The load cell applications industrial load testing , textile machinery.
Technical Parameter:
Rated Load: | 850kg |
Sensitivity: | (2.0±0.1%) mv/v |
Combined Error: | ±0.1% F.S |
Creep Error(30min): | ±0.1% F.S |
Zero Balance: | ±1% F.S |
Tco:: | ±0.02% F.S/10°C |
Tc Span:: | ±0.02% F.S/10°C |
Input Resistance: | 385±5Ω |
Output Resistance: | 351±2Ω |
Insulation Resistance: | ≥5000MΩ |
Operating Temperature Range | -30~+70°C |
Maximum Safe Over Load: | 150%F.S |
Ultimate Over Load: | 250%F.S |
Recommend Excitation Voltage: | 10~12V DC |
Maximum Excitation Voltage: | 15V DC |
Sealing Class: | IP67/IP68 |
Element Material: | Alloy Steel, Stainless Steel |
Cable: | Length=L:1.5m |
Citation | GB/T7551-1997/ OIML R60 |
Mode Of Connection | Red(Input+),Black(Input-),Green(Output+),White(Output-) |
